The Scribe’s Manual 2.0.0

𒎀 Display Note: Throughout this manual, you will see examples of cuneiform writing. If empty rectangles (▯) appear on your screen, consult the Cuneiform Support section to install the necessary fonts.

I. Foundations: The Sexagesimal Engine

1. Introduction & Quickstart

babcalc Environment

babcalc is the heart of the MesoMath ecosystem. It is a specialized REPL (Read–Eval–Print Loop) environment built upon Python 3, specifically architected to function as a seamless interactive calculator for Assyriological and mathematical research.

The babcalc interface serves two primary purposes:

• Interactive Computation: It provides a pre-configured shell where all metrological and sexagesimal classes are pre-loaded and aliased for high-speed calculation.

• Workflow Automation: It streamlines the execution of scripts by automatically resolving environment dependencies and paths, ensuring a consistent execution context regardless of your local installation method (e.g., pipx or virtual environments).

Extending the Environment: ibabcalc & Jupyter

While babcalc is the standard tool for quick calculations and automation, MesoMath offers advanced interfaces for researchers requiring more robust environments:

• ibabcalc (Interactive Poweruser Console): Built on IPython 9, this console provides an enhanced experience with syntax highlighting, advanced command history, and object introspection. It is the recommended choice for complex, multi-step session work where a clean, dedicated scribal workspace is desired.

• Jupyter Integration: For those performing data analysis or creating reproducible research (like the study of Plimpton 322), MesoMath includes specialized utilities for Jupyter Notebooks. This allows for rich-text documentation, embedded tables, and high-fidelity rendering of cuneiform glyphs using the mesomath.nb_utils module.

Note for this Tutorial: To ensure consistency and focus on core concepts, all examples and exercises in this manual will be demonstrated using the standard babcalc environment. Once you master the basics here, the same logic applies seamlessly to ibabcalc and Jupyter.

Core Concepts: Classes and Objects

For users less familiar with Object-Oriented Programming (OOP), it is helpful to understand that Classes act as blueprints. They define specific types of Objects (such as a weight or a length), their Properties (their value in different systems), and the Methods (operations like addition, reciprocal calculation, or transliteration) that can be performed upon them.

MesoMath organizes the metrology of the Old Babylonian Period (OBP) into the following optimized classes:

Class	Domain	Shortcut
BabN	Sexagesimal Place Value Numbers	bn
Blen	Length (Linear measures)	bl
Bsur	Surface (Area)	bs
Bvol	Volume (Solid/Earth/Bricks)	bv
Bcap	Capacity (Liquid/Grain)	bc
Bwei	Weight (Mass)	bw
Bbri	Brick Metrology (Counts)	bb
BsyG	Enumeration (System G)	bG
BsyS	Enumeration (System S)	bS
BsyC	Enumeration (System C)	bC
BsyK	Enumeration (System K)	bK

---

Invoking the Calculator

If you have installed MesoMath via pip, pipx, or hatch, the babcalc command is automatically added to your system’s PATH. Simply execute it to initialize the environment:

$ babcalc

The terminal will display the initialization banner, confirming that the historical metrological models are ready for use:

--- MesoMath Standard Console 2.0.0 ---

    Engine: Python 3.12.8
    Metrological classes: bl, bs, bv, bc, bw, bb, bG, bS, bC and bK loaded.
    Metrological presets: clist, wlist, slist, llist loaded.
    Use exit() or Ctrl-D (i.e. EOF) to close.

-->

Note: The --> symbol represents the primary babcalc prompt, indicating the system is ready for sexagesimal or metrological input. The Python version shown may vary reflecting your installation.

Alternatively, you can launch ibabcalc if you prefer an environment based on IPython:

$ ibabcalc

--- MesoMath Scribal Research Lab 2.0.0 ---

Powered by: IPython 9.7.0 | Python 3.12.8
Interactive environment loaded: Jupyter/IPython integration enabled.
Metrological presets (clist, wlist, etc.) ready for analysis
--------------------------------------------------------------------


In [1]:

Manual Execution

In the event that the command-line shortcut is not directly accessible, you may invoke the module via the Python interpreter:

$ python3 -m mesomath.babcalc

---

Cloud Access: The Zero-Install Experience

For an immediate start without local configuration, you can launch a live, interactive MesoMath environment directly in your browser via MyBinder.

By clicking the badge below, you will gain access to a pre-configured cloud instance containing:

• Interactive Notebooks: A collection of tutorials and curated examples (including the Plimpton 322 analysis) ready to run in Jupyter.

• Cloud Shell: A fully functional terminal to execute babcalc or ibabcalc sessions in real-time.

---

2. The BabN Class: Creating Babylonian Numbers

In MesoMath, a Babylonian Number is defined as a non-negative integer represented through sexagesimal place-value notation. The BabN class (aliased as bn in babcalc) is the fundamental engine for these numerical entities.

Core Properties and Exploration

Let us initialize a Babylonian number and examine its internal structure:

--> a = bn(405)

By querying the object’s attributes, we can observe how MesoMath maintains the duality between decimal and sexagesimal systems:

• a.dec: The decimal integer value (405).

• a.list: The sexagesimal digits represented as a Python list: [6, 45] (\(6 \times 60 + 45\)).

• a.factors: A tuple representing the prime factorization in the form \((2^i, 3^j, 5^k, l)\). For 405, this is (0, 4, 1, 1), meaning \(2^0 \cdot 3^4 \cdot 5^1 \cdot 1\).

• a.isreg: A Boolean indicating if the number is regular. A number is regular if its prime factors are limited to 2, 3, and 5, meaning it possesses a finite sexagesimal reciprocal.

• print(a): Returns the standard string representation: 6:45.

• a.rec() : Returns the reciprocal of regular numbers.

--> a = bn(405)
--> a.dec
405
--> a.list
[6, 45]
--> a.factors
(0, 4, 1, 1)
--> a.isreg
True
--> print(a)
6:45
--> a
6:45
--> a.rec()
8:53:20
--> bn(7).rec()
Not regular, (igi nu)!

The .explain() Method

For a comprehensive analysis, the .explain() method provides a detailed breakdown of the number’s mathematical properties:

--> a.explain()
|  Sexagesimal number: [6, 45] is the decimal number: 405.
|    It may be written as (2^0 * 3^4 * 5^1 * 1),
|    so, it is a regular number with reciprocal: 8:53:20

If the number is irregular (contains prime factors other than 2, 3, or 5), the method provides useful heuristics:

--> b = bn(7)
--> b.explain()
|  Sexagesimal number: [7] is the decimal number:   7.
|    It may be written as (2^0 * 3^0 * 5^0 * 7),
|    so, it is NOT a regular number and has NO reciprocal.
|    but an approximate inverse is: 8:34:17:9
|    and a close regular is: 6:59:54:14:24
|    whose reciprocal is: 8:34:24:11:51:6:40

---

Input Flexibility

MesoMath supports four distinct methods for instantiating Babylonian numbers, allowing you to work with decimal data, digit lists, literal strings, or prime factors:

1. Decimal: bn(405)

2. Digit List: bn([6, 45])

3. Literal String: bn('6:45') or bn("6.45")

4. Factors (Tuple): bn((0, 4, 1, 1))

All these methods yield identical objects:

--> bn(405) == bn([6, 45]) == bn('6:45') == bn((0, 4, 1, 1))
True

Implementation Note: The BabN class handles non-negative integers only. If a negative value is passed (e.g., bn(-405)), the class will automatically use the absolute value.

---

Formatting and Separators

By default, MesoMath uses the colon (:) as the digit separator. However, this is globally configurable via the bn.sep attribute to match different publication styles:

--> n1 = bn(314159265)
--> n1
24:14:26:27:45
--> bn.sep = '.'
--> n1
24.14.26.27.45

When parsing strings, the bn constructor is highly resilient and can interpret multiple separators (:, ;, ., ,,-) and blank space ( ) simultaneously:

--> bn('1:2;3,4.5 6-7')
1:2:3:4:5:6:7

Digit Count

To determine the precision or “length” of a number (the number of sexagesimal places it occupies), you can use either the class method .len() or the standard Python len() function:

--> m = bn('3:14:16')
--> len(m)
3

3. The Arithmetic of Clay: Operations, Roots, Reciprocals and logic.

MesoMath assumes a foundational understanding of Mesopotamian mathematics, particularly the distinction between absolute and floating sexagesimal notation, as well as the properties of regular and reciprocal numbers.

3.1 Basic Arithmetic

Addition and Subtraction

In MesoMath, addition and subtraction are absolute operations. Unlike modern algebra, Mesopotamian mathematics did not utilize negative numbers. To prevent errors and align with historical logic, subtraction in BabN returns the absolute difference. Consequently, subtraction is commutative by design:

--> bn(45689) - bn(325874)
1:17:49:45
--> bn(325874) - bn(45689)
1:17:49:45

Addition supports multiple addends and direct interaction with standard Python integers:

--> a = bn('16:24:35')
--> a + 34 + bn('1:33:54:22')
1:50:19:31

If a floating result is required (normalizing the number by removing trailing zeros), use the .float() method or its shortcut .f():

--> c = bn('40:16:37:0:0')
--> c.f()
40:16:37

Multiplication and Powers

Multiplication is absolute by default, but its behavior can be globally toggled via the bn.floatmult attribute. Powers are handled via the standard ** operator:

--> bn(3)*bn(140)
7:0
--> bn.floatmult = True
--> bn(3)*bn(140)
7
--> bn.floatmult = False
--> bn(3)*bn(140)
7:0
--> a = bn('34:59:31:12')
--> a**2
20:24:26:24:13:49:26:24
--> a**3
11:54:5:36:24:11:24:33:52:7:40:48

Division: Modern vs. Babylonian

MesoMath distinguishes between two conceptual approaches to division:

1. Modern Division (a / b): An approximate floating-point division. It converts sexagesimal values to a decimal-like quotient for the convenience of the modern researcher. The precision is controlled by bn.rdigits.

--> bn(34)/7
4:51:25:42:51:25:43
--> bn(34)/bn(7)
4:51:25:42:51:25:43
--> 34/bn(7)
4:51:25:42:51:25:43

2. Babylonian Division (a // b): Historically accurate division via the product of the reciprocal. This operation requires the divisor b to be a regular number.

--> a = bn('14:15:16')
--> b = bn(405) # Regular: 6:45
--> a // b
2:6:42:22:13:20
--> a//bn(7)
Divisor is not a regular number (igi nu)!

---

3.2 Root Extraction

MesoMath provides methods for calculating floating-point square (.sqrt()) and cube (.cbrt()) roots. These tools are essential for verifying tablet calculations, such as the famous diagonal of the square in YBC 7289.

--> bn(2).sqrt()
1:24:51:10:7:46

By multiplying this result by 30 (the side of the square), we can replicate the exact value inscribed by the apprentice scribe over 3,700 years ago:

--> (30 * bn(2).sqrt()).f()
42:25:35

The class attribute rdigitis controls the number of digits in some results. For example,

--> bn(2).sqrt()
1:24:51:10:7:46
--> bn.rdigits = 10
--> bn(2).sqrt()
1:24:51:10:7:46:6:4:44:52

---

3.3 Logical Operations and Complex Expressions

Because MesoMath is built upon Python, BabN objects integrate seamlessly with standard logic and data structures (lists, comprehensions, etc.).

Filtering for Regularity: A common research task is identifying regular numbers within a range. This can be achieved with a single line of Python code:

--> [bn(i) for i in range(400, 410) if bn(i).isreg]
[6:40, 6:45]

Logical Comparisons:

--> a = bn('16:22')
--> b = bn('44:16')
--> a < b and a.isreg
True

---

3.4 Formatting: The bn.fill Attribute

For researchers generating tables or requiring consistent digit widths, the bn.fill attribute toggles zero-padding for single-digit sexagesimal values (0-9).

--> z = bn('1:2:0:14:5')
--> bn.fill = True
--> z
01:02:00:14:05

This global setting ensures that printed outputs align perfectly in columns, facilitating the creation of professional-grade metrological or mathematical lists.

4. Precision and Heuristic Tools

The BabN class includes a suite of methods designed to handle approximations, reciprocals, and digit manipulation—essential for replicating the iterative processes of ancient calculators.

4.1 Reciprocals and Inverses

In the Babylonian system, division is conceptualized as multiplication by a reciprocal. MesoMath provides two ways to handle this:

• .rec() (Reciprocal): Returns the exact reciprocal of a regular number. If the number is irregular (possessing prime factors other than 2, 3, or 5), it returns None.

• .inv(n) (Inverse): A heuristic method for irregular numbers. Since irregular numbers have infinite sexagesimal expansions, .inv(n) calculates the first n digits of the approximation.

--> a = bn(400) # 6:40
--> a.rec()
9
--> b = bn(406) # 6:46 (Irregular)
--> b.rec()
Not regular, (igi nu)!
--> b.inv(4)
08:52:01:11

4.2 Digit Slicing and Rounding

When working with long floating-point strings, researchers often need to truncate or round results to match the precision found on specific tablets.

• .round(n): Returns the first n digits with standard rounding. This can also be invoked via the standard Python round(obj, n) function.

• .head(n): Truncates the number, returning the first n digits without rounding.

• .tail(n): Returns the final n digits, useful for analyzing remainders or lower-order values.

--> c = bn('8:52:1:10:56:9:27')
--> c.round(4)
8:52:1:11
--> c.head(3)
8:52:1
--> c.tail(2)
9:27

4.3 The Heuristic Search: .searchreg()

A sophisticated feature of MesoMath is the ability to find the “closest regular” number to an irregular target. This mirrors the technique used by ancient scribes who substituted irregular values with nearby regular approximations to facilitate further calculations.

The .searchreg(minn, maxn, limdigits=6, prt=False) method queries an internal database to find the best candidate within a specified range:

--> bn(7).searchreg('06:40', '07:40', 4, prt=True)
        72000 06:40
        54000 06:45
        37440 06:49:36
        35775 06:50:03:45
        19008 06:54:43:12
        12000 06:56:40
         6750 07:01:52:30
        24000 07:06:40
        43200 07:12
        50500 07:14:01:40
        60864 07:16:54:24
        62640 07:17:24
        82323 07:22:52:03
        88000 07:24:26:40
       108000 07:30
       126400 07:35:06:40
       128250 07:35:37:30
Minimal distance: 6750, closest regular is: 07:01:52:30
07:01:52:30

Note on Distance: MesoMath uses a specialized “floating distance” (.dist()). Unlike decimal distance, this metric prioritizes the similarity of the most significant digits (the “head” of the number), correctly identifying that 7 is closer to 6:59:54:14:24 than to 7:10.

---

4.4 Accessing Documentation: help()

MesoMath is fully documented internally. If you are unsure about the parameters of a method or its default values, you can use the built-in Python help() system directly from the babcalc prompt:

--> help(bn.searchreg)

This will display the docstring for the method, including parameter types and return values. (Press q to return to the prompt).

5. Cuneiform Representation

The BabN class can transform any sexagesimal number into its equivalent Unicode cuneiform signs. This is not a static mapping but a dynamic rendering that supports different scribal styles.

Using the .cuneiform() method, you can visualize the number directly:

--> a = bn('1:12:0:52:37')
--> print(a.cuneiform())
  𒐕 𒌋𒐖  𒐐𒐖 𒌍𒑂  

MesoMath allows for nuanced control over the paleography through parameters:

• alter=True: Uses alternative sign forms for certain values (e.g., variant forms of 40 or 50).

• stroke=True: Adds structural or separation strokes where historically applicable to improve readability.

--> # Using alternative signs and strokes for a more distinct rendering
--> print(a.cuneiform(alter=1, stroke=1))
 𒐕 𒌋𒐖 𒃵 𒑪𒐖 𒌍𒑂  

Tip: Use help(bn.cuneiform) to see all available styles and stroke options. Note that the output relies on having a Cuneiform Unicode font installed on your system.

6. Multiplication Tables

In the Babylonian Edubba (tablet house), learning the multiplication tables of “principal” numbers was a foundational requirement for any scribe. MesoMath replicates this experience through the .multable() method, allowing you to generate these tables instantly for any sexagesimal value.

5.1 The Internal Method: .multable()

Unlike standard calculators, MesoMath allows a BabN object to “reveal” its own multiplication table. By default, it follows the ancient scribal tradition of displaying products for the multipliers: 1–20, 30, 40, and 50.

--> n = bn(9)
--> n.multable()

|  i  | i * 9|
|-----|------|
|  1  |    9 |
|  2  |   18 |
|  3  |   27 |
|  4  |   36 |
|  5  |   45 |
|  6  |   54 |
|  7  |  1:3 |
|  8  | 1:12 |
|  9  | 1:21 |
| 10  | 1:30 |
| 11  | 1:39 |
| 12  | 1:48 |
| 13  | 1:57 |
| 14  |  2:6 |
| 15  | 2:15 |
| 16  | 2:24 |
| 17  | 2:33 |
| 18  | 2:42 |
| 19  | 2:51 |
| 20  |  3:0 |
| 30  | 4:30 |
| 40  |  6:0 |
| 50  | 7:30 |

5.2 Advanced Options

The .multable() method is highly customizable to suit different research needs:

• Full Tables (pral=False): Generates a continuous table from 1 to 59.

• Indices (indices=[2,4,17]): Generates a table only for the given numbers.

• Floating Point (floating=True): Displays results in sexagesimal floating-point notation (useful for complex reciprocal calculations).

• Cuneiform Output (cuneiform=True): Renders the entire table in original characters, including the multiplication operator label.

5.3 Cuneiform Tables

When using the cuneiform=True flag, MesoMath uses the TIMES_LABEL glyph and properly aligns the columns to provide a high-fidelity digital reconstruction of a clay tablet.

--> n = bn(25)
--> n.multable(cuneiform=True, stroke=True)

|   𒎙𒐙  𒀀 𒁺  𒐕  |    𒎙𒐙 |
|---------------|-------|
|       𒀀 𒁺   𒐖 |    𒑪  |
|       𒀀 𒁺   𒐗 |  𒐕 𒌋𒐙 |
|       𒀀 𒁺   𒐘 |  𒐕 𒑩  |
|       𒀀 𒁺   𒐙 |  𒐖  𒐙 |
|       𒀀 𒁺   𒐚 |  𒐖 𒌍  |
|       𒀀 𒁺   𒑂 |  𒐖 𒑪𒐙 |
|       𒀀 𒁺   𒑄 |  𒐗 𒎙  |
|       𒀀 𒁺   𒑆 |  𒐗 𒑩𒐙 |
|       𒀀 𒁺  𒌋  |  𒐘 𒌋  |
|       𒀀 𒁺  𒌋𒐕 |  𒐘 𒌍𒐙 |
|       𒀀 𒁺  𒌋𒐖 |   𒐙 𒃵 |
|       𒀀 𒁺  𒌋𒐗 |  𒐙 𒎙𒐙 |
|       𒀀 𒁺  𒌋𒐘 |  𒐙 𒑪  |
|       𒀀 𒁺  𒌋𒐙 |  𒐚 𒌋𒐙 |
|       𒀀 𒁺  𒌋𒐚 |  𒐚 𒑩  |
|       𒀀 𒁺  𒌋𒑂 |  𒑂  𒐙 |
|       𒀀 𒁺  𒌋𒑄 |  𒑂 𒌍  |
|       𒀀 𒁺  𒌋𒑆 |  𒑂 𒑪𒐙 |
|       𒀀 𒁺  𒎙  |  𒑄 𒎙  |
|       𒀀 𒁺  𒌍  | 𒌋𒐖 𒌍  |
|       𒀀 𒁺  𒑩  | 𒌋𒐚 𒑩  |
|       𒀀 𒁺  𒑪  | 𒎙  𒑪  |

The previous cuneiform output should appear correctly aligned on almost any modern terminal; but, due to the variable width of the cuneiform glyphs, it is next to impossible to get it to appear aligned in an HTML document like this using a monospaced font, so henceforth the outputs will be presented in table format.

𒎙𒐙  𒀀 𒁺 𒐕	𒎙𒐙
𒀀 𒁺 𒐖	𒑪
𒀀 𒁺 𒐗	𒐕 𒌋𒐙
𒀀 𒁺 𒐘	𒐕 𒑩
𒀀 𒁺 𒐙	𒐖  𒐙
𒀀 𒁺 𒐚	𒐖 𒌍
𒀀 𒁺 𒑂	𒐖 𒑪𒐙
𒀀 𒁺 𒑄	𒐗 𒎙
𒀀 𒁺 𒑆	𒐗 𒑩𒐙
𒀀 𒁺 𒌋	𒐘 𒌋
𒀀 𒁺 𒌋𒐕	𒐘 𒌍𒐙
𒀀 𒁺 𒌋𒐖	𒐙 𒃵
𒀀 𒁺 𒌋𒐗	𒐙 𒎙𒐙
𒀀 𒁺 𒌋𒐘	𒐙 𒑪
𒀀 𒁺 𒌋𒐙	𒐚 𒌋𒐙
𒀀 𒁺 𒌋𒐚	𒐚 𒑩
𒀀 𒁺 𒌋𒑂	𒑂  𒐙
𒀀 𒁺 𒌋𒑄	𒑂 𒌍
𒀀 𒁺 𒌋𒑆	𒑂 𒑪𒐙
𒀀 𒁺 𒎙	𒑄 𒎙
𒀀 𒁺 𒌍	𒌋𒐖 𒌍
𒀀 𒁺 𒑩	𒌋𒐚 𒑩
𒀀 𒁺 𒑪	𒎙  𒑪

Note: As you can see, the previous output is in Markdown table format, so if you use Markdown for your documents, you’re in luck, you just have to copy and paste the result from the terminal into your document and that’s it. But you can also paste it into an intermediate .csv file that can be read by any spreadsheet (indicating the pipe | character as the column separator) and from there you can copy and paste it into your word processor or presentations.

𒎙𒐙  𒀀 𒁺 𒐕	𒎙𒐙
𒀀 𒁺 𒐖	𒑪
𒀀 𒁺 𒐗	𒐕 𒌋𒐙
𒀀 𒁺 𒐘	𒐕 𒑩
𒀀 𒁺 𒐙	𒐖  𒐙
𒀀 𒁺 𒐚	𒐖 𒌍
𒀀 𒁺 𒑂	𒐖 𒑪𒐙
𒀀 𒁺 𒑄	𒐗 𒎙
𒀀 𒁺 𒑆	𒐗 𒑩𒐙
𒀀 𒁺 𒌋	𒐘 𒌋
𒀀 𒁺 𒌋𒐕	𒐘 𒌍𒐙
𒀀 𒁺 𒌋𒐖	𒐙 𒃵
𒀀 𒁺 𒌋𒐗	𒐙 𒎙𒐙
𒀀 𒁺 𒌋𒐘	𒐙 𒑪
𒀀 𒁺 𒌋𒐙	𒐚 𒌋𒐙
𒀀 𒁺 𒌋𒐚	𒐚 𒑩
𒀀 𒁺 𒌋𒑂	𒑂  𒐙
𒀀 𒁺 𒌋𒑄	𒑂 𒌍
𒀀 𒁺 𒌋𒑆	𒑂 𒑪𒐙
𒀀 𒁺 𒎙	𒑄 𒎙
𒀀 𒁺 𒌍	𒌋𒐖 𒌍
𒀀 𒁺 𒑩	𒌋𒐚 𒑩
𒀀 𒁺 𒑪	𒎙  𒑪

Warning: If you are using the legacy bmultable.py script, we strongly recommend migrating your workflow to the .multable() method. The standalone script is considered obsolete and will be removed in the final stable 2.0.0 release.

---

Summary of Parameters

Parameter	Type	Default	Description
pral	bool	True	If True, only prints the traditional “principal” multipliers.
cuneiform	bool	False	Switches output to Unicode Cuneiform characters.
floating	bool	False	Displays results as sexagesimal floating point numbers.
sep	str	":"	Custom separator for sexagesimal digits in ASCII mode.
stroke	bool	False	In cuneiform mode, uses a specific stroke for empty positional values (zeroes).

---

II. Metrology: The Weight of Tradition

The metrological engine of MesoMath is designed to handle the complex, non-linear systems of the Old Babylonian Period (OBP). Unlike the metric system, where conversion is a simple shift of the decimal point, Babylonian metrology relies on specific coefficients and discrete systems for different domains.

1. The Four Pillars and the Specificity of Classes

MesoMath defines several specialized classes to represent different physical domains. While a modern mathematician might treat surfaces, volumes, and brick counts as “just numbers,” the Babylonian scribe—and consequently this library—treats them as distinct ontological categories because they support different mathematical operations and socio-economic rules.

Class	Domain	Base Unit
Blen	Length	ninda (approx. 6m)
Bsur	Surface	sar (approx. 36m²)
Bvol	Volume	sar (standard thickness of 1 kuš3)
Bcap	Capacity	gur (approx. 300 litres)
Bwei	Weight	gu2 (talent, approx. 30kg)
Bbri	Bricks	sar (standardized brick volumes)

The Volume-Surface Equivalence (The 1-cubit Rule)

In Babylonian mathematics, Volumes (Bvol) and Brick counts (Bbri) are expressed using the same units as Surfaces (Bsur). This is not a coincidence:

• A volume is conceptually a “surface with a standardized thickness” of 1 kuš3 (cubit).

• Therefore, a volume of 1 sar represents a block with a base of 1 sar (1x1 ninda) and a height of 1 kuš3.

Why separate classes?

Although they share units (like the sar), MesoMath uses separate classes because:

1. Validation: It prevents the accidental addition of a weight (Bwei) to a capacity (Bcap).

2. Specialized Methods: Bbri (Bricks) includes methods for counting physical units that Bsur does not need.

3. Epigraphy: Transliteration rules can vary slightly depending on whether you are describing a field or a pile of grain.

---

2. The “Vertical Problem”: Defining Height

A common question for new users is: “Where is the class for vertical lengths (height/depth)?”

In the OBP system, vertical measures (heights of walls, depths of canals) are technically lengths. However, while horizontal lengths are measured in ninda, vertical measures are almost exclusively recorded in kuš3.

MesoMath does not include a separate Bheight class by default because:

• Mathematically, it is redundant; any vertical measure is a Blen object.

• The system is designed to favor the ninda as the primary sexagesimal unit for Blen, which is the standard for mathematical tablets.

User Extension: If your specific research involves heavy interaction between vertical and horizontal measures and you prefer the semantic clarity of a dedicated class, you can easily extend the metrology to create one. However, for 99% of applications, using Blen with the appropriate unit (e.g., bl('2 kuš3')) is the historically accurate and functionally sufficient approach.

---

3. Basics of Metrological Classes

MesoMath handles historical metrology through specialized classes. While these classes are pre-imported in babcalc (as bl, bc, bw, etc.), their full academic names and internal structures are essential for advanced scripting and research.

3.1 The Metrological Systems (OBP)

Each class represents a specific physical domain with its own hierarchy of units and conversion factors:

Measurements

• bl (Length): danna <-30- UŠ <-60- ninda <-12- kuš3 <-30- šu-si

• bs/bv/bb (Surface/Volume/Bricks): GAN2 <-100- sar <-60- gin2 <-180- še

• bc (Capacity): gur <-5- bariga <-6- ban2 <-10- sila3 <-60- gin2 <-180- še

• bw (Weight): gu2 <-60- ma-na <-60- gin2 <-180- še

Sexagesimal NPVS; Specialized counting systems

• bG: šar2-gal <-6- šar'u <-10- šar2 <-6- bur'u <-10- bur3 <-3- eše3 <-6- iku

• bS: šar2-gal <-6- šar'u <-10- šar2 <-6- geš'u <-10- geš <-6- u <-10- aš

• bK: šar2-gal <-6- šar'u <-10- šar2 <-6- geš'u <-10- geš <-6- u <-10- diš

3.2 Unit Names and Schemas

For ease of use in the REPL, unit names have been simplified (e.g., susi for šu-si, kus for kuš3). You can query any class to see its internal schema and academic nomenclature:

--> bc.uname   # Simplified names for input
['se', 'gin', 'sila', 'ban', 'bariga', 'gur']

--> bc.aname   # Academic names with diacritics
['še', 'gin2', 'sila3', 'ban2', 'bariga', 'gur']

--> bc.cname()
['𒊺', '𒂆', '𒋡', '𒑏', '𒉿', '𒄥']

--> print(*bc.scheme(bc, 0)) # Visual representation of the hierarchy
gur <-5- bariga <-6- ban2 <-10- sila3 <-60- gin2 <-180- še

--> print(*bc.scheme(bc, 1)) # Cuneiform representation of the hierarchy
𒄥   ╼5╾  𒉿   ╼6╾  𒑏   ╼10╾  𒋡   ╼60╾  𒂆   ╼180╾  𒊺

---

3.3 Defining Measurements

You can instantiate metrological objects using two primary methods:

1. Smallest Unit (Integer): Passing a raw integer represents the total count of the smallest unit in that system.

2. String Literal: A descriptive string using unit names.

--> a = bl(11111)              # 11,111 susi
--> b = bl('5 ninda 25 susi')  # Textual definition
--> a
30 ninda 10 kus 11 susi
--> b
5 ninda 25 susi
--> a.dec
11111                          # total count of the smallest unit
--> b.dec
1825

3.4 The .sex() and .explain() Methods

To bridge the gap between concrete metrology and sexagesimal abstraction, the .sex(unit_index) method calculates the sexagesimal floating value relative to a specific unit in the hierarchy.

• a.sex(2): Calculates the value relative to the 3rd unit (index 2), which for lengths is the ninda.

--> bl.uname
['susi', 'kus', 'ninda', 'us', 'danna']
--> bl.uname[2]
'ninda'

This is the engine used to recreate historical metrological lists:

--> bl('1 kus').sex(2)  # 1 kus as a fraction of a ninda (1/12)
5
--> bl('1 kus').sex(1)  # 1 kus as a fraction of a kus (1)
1
--> bl('1 kus').sex()  # 1 kus as a multiple of a susi (30) (Default = 0)
30

For a complete overview, including the approximate International System (SI) equivalent, use .explain():

--> bl('1 kus').explain()
This is a Babylonian length measurement: 1 kus
    Metrology:  danna <-30- us <-60- ninda <-12- kus <-30- susi
    Factor with unit 'susi':  1 30 360 21600 648000
Measurement in terms of the smallest unit: 30 (susi)
Sexagesimal floating value of the above: 30
Approximate SI value: 0.5 meters

---

4. Metrological Operations

MesoMath objects are aware of their dimensional nature. They allow for both intra-class arithmetic and inter-class geometric operations.

4.1 Intra-class Arithmetic

Objects of the same class support addition, subtraction (absolute difference), and scaling by a number.

--> a = bl('1 ninda')
--> b = bl('2 kus')
--> a + b
1 ninda 2 kus

--> a - b == b - a   # Subtraction is commutative (absolute difference)
True

--> a * 2.5          # Scaling by a factor
2 ninda 6 kus
--> c=bl(11111)
--> c
30 ninda 10 kus 11 susi
--> c*2
1 us 1 ninda 8 kus 22 susi
--> c/2
15 ninda 5 kus 6 susi  # Rounding!!
--> 2*(c/2)
30 ninda 10 kus 12 susi

4.2 Geometric Interaction (Dimensionality)

MesoMath enforces logical geometric rules through Dimensional Awareness. You can multiply lengths to generate surfaces, and surfaces by lengths to generate volumes. Conversely, you can divide these higher-order magnitudes to find missing linear or planar dimensions.

However, “illegal” operations (like multiplying two volumes or dividing a length by a surface) are prohibited to maintain historical and physical consistency.

Building Up: Multiplication

Assembling a 3D structure follows the logical progression from \(L \to S \to V\).

--> length = bl('10 ninda')
--> width  = bl('5 ninda')
--> height = bl('2 kus')

--> surface = length * width      # returns a Bsur object (50 sar)
--> volume  = surface * height    # returns a Bvol object (1 2/3 sar)
--> volume2 = length * width * height
--> volume == volume2
True

Breaking Down: Division

MesoMath overloads the division operator to perform Dimensional Descent. This allows you to solve for a missing side or height directly.

• Surface / Length = Length (\(S / L \to L\))

• Volume / Length = Surface (\(V / L \to S\))

• Volume / Surface = Length (\(V / S \to L\))

--> # Finding the missing side of a 1 sar rectangle
--> area = bs('1 sar')
--> side_a = bl('3 ninda')
--> side_b = area / side_a
--> side_b.prtf()
'1/3 ninda'

--> # Finding the height of a canal from its volume and base area
--> total_vol = bv('10 sar')
--> base_area = bs('20 sar')
--> canal_depth = total_vol / base_area
--> canal_depth.prtf()
'1/2 kus'

--> # Finding the surface area from volume and a known linear dimension
--> width = bl('1/2 ninda')
--> canal_surface = total_vol / width
--> canal_surface
2(u) gan2

Scaling and Distribution

You can also divide any magnitude by a scalar (integer or float) for equal distribution or scaling without changing the dimension of the object.

--> # Dividing a field of 1 gan2 among 3 brothers
--> field = bs('1 gan2')
--> share = field / 3
--> share
33 1/3 sar

Engineering Note: In these operations, MesoMath automatically handles the internal conversion factors (e.g., the implicit thickness of \(1 \text{ kuš}_3\) in volumes) and rounds the result to the nearest integer of the system’s smallest unit.

4.3 SI Conversion & Modern Interoperability

MesoMath provides a robust bridge between ancient units and the International System of Units (SI). This allows researchers to translate archaeological field data directly into Babylonian metrological objects.

From Ancient to Modern: .si() and .SI()

To obtain the approximate modern equivalent of a Babylonian measure, use .si() for a raw float or .SI() for a formatted string including the unit name.

--> w = bw('1 mana 3 gin')
--> w.si()
0.525
--> w.SI()
'0.525 kilograms'

From Modern to Ancient: .from_si()

Reciprocally, the @classmethod .from_si() allows you to instantiate a metrological object starting from a modern value (meters, kilograms, square meters, cubic meters, or brick counts).

--> # Converting 0.572 kg to Babylonian weight
--> a = bw.from_si(0.572)
--> a
1 mana 8 gin 115 se

--> # Checking the precision loss after conversion
--> a.SI()
'0.5719907407407407 kilograms'

--> # Converting a modern brick count to Babylonian Brick Metrology (Bbri)
--> bricks_total = bb.from_si(1700)
--> bricks_total
2 sar 21 gin 120 se
--> bricks_total.SI()
'1700.0 bricks'

Precision Note: Since Babylonian metrology is based on discrete “units of account” (integers of the smallest unit), .from_si() uses a round() function. The small discrepancy seen in the example (0.57199... vs 0.572) reflects the historical granularity of the system.

5. Advanced Metrological Input and Representation

Mesopotamian scribes did not always record quantities as simple counts. Depending on the system (capacity, surface, etc.), they used specific sexagesimal notations known as Systems S, G, C, and K. MesoMath allows you to toggle between modern simplified output and these historical “sexagesimalized” representations.

5.1 Historical Sexagesimal Modes (Systems C, S and G)

By default, metrological objects display their values using simplified unit names and absolute decimal counts. However, you can switch to a mode that mimics the way measurements were actually inscribed on clay by grouping coefficients into higher-order sexagesimal signs (bur3, iku, geš2, etc.), see Appendix A for details on the use of systems C, S and G.

To activate this for a specific class (e.g., Volumes):

--> bv.prtsex = True  # Enable historical sexagesimal grouping
--> a = bv('128 gan')
--> a
(7 bur 2 iku) gan
--> b=bw(11223344)
--> b
17 gu 19 mana 11 gin 164 se
--> bw.prtsex = True  # also: bw.prtsex = 1
--> b
(1 u 7 as) gu (1 u 9 dis) mana (1 u 1 dis) gin (2 ges 4 u 4 as) se

To apply this behavior globally to all metrological classes, use the master controller:

from mesomath.npvs import MesoM
MesoM.prtsex = True

5.2 The Third Input Method: Parenthetical Strings

As a direct consequence of the historical mode, MesoMath supports a third input method. This method is highly resilient and allows you to copy-paste complex strings (even those with parentheses) directly into the constructor. For instance, continuing from above:

--> c = bw('(1 u 7 as) gu (1 u 9 dis) mana (1 u 1 dis) gin (2 ges 4 u 4 as) se')
--> b == c
True
--> c.dec
11223344

The system can even interpret sexagesimal coefficients directly:

--> d = bv('2:8:0:0 gan 44 sar 20 gin')
--> d
(7 sargal 6 sar 4 buru) gan (4 u 4 dis) sar (2 u) gin

---

5.3 Fractional Support

The Babylonian system relied heavily on a specific set of principal fractions: \(1/6, 1/3, 1/2, 2/3,\) and \(5/6\). MesoMath supports these fractions for both input and output.

Inputting Fractions: Fractions can be entered using various natural syntaxes within the string literal:

--> bl('1/3 ninda')        # Simple fraction
4 kus
--> bl('2 1/3 ninda')      # Integer + fraction
2 ninda 4 kus
--> bl('2 + 1/3 ninda')    # Explicit addition
2 ninda 4 kus

Outputting Fractions (.prtf()): To generate a human-readable string that utilizes these fractions, use the .prtf() method.

• prtf(): Uses standard fractions (\(1/3, 1/2, 2/3, 5/6\)).

• prtf(1): Includes the less frequent \(1/6\) fraction.

--> a = bl(11223344)
--> bl.prtsex = 0
--> a.prtf()
'17 danna 9 1/2 us 5 5/6 ninda 1 1/3 kus 4 susi'

If prtsex is active, the fractions are seamlessly integrated into the historical notation:

--> bl.prtsex = True
--> a.prtf()
'(1 u 7 dis) danna (9 dis) 1/2 us (5 dis) 5/6 ninda (1 dis) 1/3 kus (4 dis) susi'

and this result can also be used as input:

--> b = bl('(1 u 7 dis) danna (9 dis) 1/2 us (5 dis) 5/6 ninda (1 dis) 1/3 kus (4 dis) susi')
--> a == b
True

---

5.4 Academic Nomenclature

For final publications or formal research notes, you may require the exact academic names of units (including diacritics and Sumerian/Akkadian terminology like kuš3 or šu-si).

The .prtf() method accepts a second parameter (academic=True) to toggle this nomenclature:

--> a = bl(11223344)
--> # Using both fraction extension and academic names:
--> a.prtf(1, 1)  # bl.prtsex = True !!
'(1 u 7 diš) 1/6 danna (4 diš) 1/2 UŠ (5 diš) 5/6 ninda (1 diš) 1/3 kuš3 (4 diš) šu-si'

Crucially, MesoMath’s parser is symmetrical: any string generated by .prtf()—including those with parentheses, fractions, and academic diacritics—is valid input for creating new objects.

--> b = bl(a.prtf(1, 1))
--> b.dec
11223344

You can also use .acad to view academic names without fractions:

--> b
(1 u 7 dis) danna (9 dis) us (3 u 5 dis) ninda (1 u 1 dis) kus (1 u 4 dis) susi
--> b.acad
'(1 u 7 diš) danna (9 diš) UŠ (3 u 5 diš) ninda (1 u 1 diš) kuš3 (1 u 4 diš) šu-si'

---

6. Volume, Capacity, and Brick Metrology

In Mesopotamia, the concept of “volume” diverged based on the physical nature of the substance being measured. MesoMath respects this historical distinction through specialized classes that allow for fluid conversion between administrative domains.

6.1 Volume vs. Capacity

There were two distinct systems for measuring three-dimensional space:

• Capacity (Bcap / bc): Used for “hollow” measures such as grain, beer, and other commodities. Its primary unit is the sila (approx. 1 liter).

• Volume Proper (Bvol / bv): Used for “solid” measures such as earth, canals, and architectural structures. Its primary unit is the sar (approx. 18 m³).

Since both systems measure the same physical magnitude, MesoMath provides direct conversion methods: .cap() and .vol().

--> a = bv('1 gin')
--> b = a.cap()  # Convert volume to capacity
--> b
1 gur
--> b.vol()  # Convert back to volume
1 gin

• Note: In the Babylonian system, 1 gin2 of volume is exactly equivalent to 1 gur of capacity.

---

6.2 Brick Metrology (Bbri)

The calculation of bricks is one of the most sophisticated applications of Babylonian mathematics. Rather than counting individual bricks, scribes used the sar-b (a unit representing a “stack” or volume of 720 bricks) and the concept of the Nalbanum.

The Nalbanum: This is a conversion coefficient. While the physical volume of a wall remains constant, the number of bricks required depends on their specific dimensions. The Nalbanum acts as the multiplier to translate “theoretical volume” into an “actual brick count.”

Using the .bricks() Method

By default, MesoMath assumes a Nalbanum of 1.0 (Standard Type-12 brick). For other historical types, pass the coefficient as an argument:

--> wall_volume = bv('1 sar')
--> # Calculating for Type-2 bricks (Nalbanum 7.20)
--> brick_count = wall_volume.bricks(7.2)
--> brick_count.SI()
'5184.0 bricks'

The Brick Unit: 15 še

Internally, MesoMath defines a single standard brick as equivalent to 15 še. This allows you to instantiate Bbri objects directly from a known count:

--> # Creating an object for a shipment of 10,000 bricks
--> shipment = bb(15 * 10000)
--> shipment.SI()
'10000.0 bricks'
--> # Convert back to physical volume for a specific brick type
--> shipment.vol(7.2).SI()
'34.721666666666664 cube meters'

but you can also use the .from_si() method:

--> shipment = bb.from_si(10000)
--> shipment.SI()
'10000.0 bricks'
--> shipment.vol(7.2).SI()
'34.721666666666664 cube meters'

---

6.3 Reference: Nalbanum Table

The following table details the coefficients for common brick types based on archaeological and mathematical evidence (notably the work of Robson and Maza):

Brick Type	Nalbanum (Dec.)	Nalbanum (Sex.)	Description
Type 1	9.00	9	Standard square brick (sig-al-ur-ra)
Type 1a	8.33	8:20	Variant square form
Type 2	7.20	7:12	2/3 kuš3 brick
Type 4	5.00	5	Standard rectangular brick
Type 12	1.00	1	Unit reference for transport logistics

---

⚠️ Crucial Metrological Note

As established in the foundations of this manual, in Babylonian metrology, Volumes and Bricks are treated identically to Surfaces.

• Objects of class Bvol and Bbri utilize the same unit hierarchy as Bsur (sar, gin2, še).

• This reflects the ancient conception of volume as a surface area with a default thickness of 1 kuš3 (cubit).

• Structural Integrity: To maintain physical consistency, MesoMath allows multiplying Surface * Length to yield a Volume, but strictly prohibits multiplying Volume * Length. This prevents the inadvertent creation of four-dimensional “hyper-volumes,” which remained outside the scope of scribal praxis.

---

What’s Next?

Now that we have covered the diverse metrological domains, we will explore the .metrolist() method in the next section. This tool allows the researcher to automatically generate reference tables and simulate the school-text lists used by ancient apprentices.

7. Generating Reference Tables: The .metrolist() Method

MesoMath does not just calculate; it generates structured data. The .metrolist() family of methods allows you to create segments of metrological lists and tables in various formats, from simple terminal output to academic \(\LaTeX\).

7.1 Method Overview

Depending on your final destination, MesoMath provides different “siblings” for the same generation engine:

Format	Method	Best For
Markdown / Terminal	.metrolist()	Quick reference and documentation.
HTML	.metrohtml()	Web publishing and Sphinx documentation.
Academic (\(\LaTeX\))	.metrolatex()	Direct inclusion in papers and books.
Data Science (CSV)	.metrocsv()	Analysis in spreadsheets or R/Pandas.

Note: Everything above depends internally on the .metro_generator() class method. Use, for example, --> help(bl.metro_generator) to see a complete list of options.

7.2 Basic Usage

The .metrolist() method requires three core parameters: Initial Value, Final Value, and Increment. These can be provided as unit strings or as raw integers (representing the smallest unit).

--> # Creating a list of weights from 10 gin to 1 mana in 10-gin steps
--> bw.metrolist('10 gin', '1 mana', '10 gin')

Babylonian weight measurement
gu <-60- mana <-60- gin <-180- se
|Measurement         |
|--------------------|
|10 gin              |
|20 gin              |
|30 gin              |
|40 gin              |
|50 gin              |
|1 mana              |

7.3 Advanced Table Features

By using optional parameters, you can transform a simple list into a complex comparative table:

• verbose=True: Adds columns for the Sexagesimal value and the Reciprocal (crucial for division problems).

• fractions=1 (or 2): Automatically converts measurements to their fractional representations (\(1/3\), \(1/2\), \(2/3\), \(5/6\), and \(1/6\)).

• actual=True: Uses the academic unit names (e.g., ma-na instead of mana).

• echo=False: Instead of printing, it returns the table as a Python list of strings for script processing.

--> # A comprehensive table with fractions and sexagesimal grouping enabled
--> bw.prtsex = True
--> bw.metrolist('10 gin', '1 mana', '10 gin', verbose=True, fractions=1)

Babylonian weight measurement
gu <-60- mana <-60- gin <-180- se
|Measurement         | Sexag. (gin)    | Reciprocal  |
|--------------------|-----------------|-------------|
|(1 u) gin           | 10              | 6           |
|1/3 mana            | 20              | 3           |
|1/2 mana            | 30              | 2           |
|2/3 mana            | 40              | 1:30        |
|5/6 mana            | 50              | 1:12        |
|(1 dis) mana        | 1               | 1           |

---

7.4 Segmented Lists (Historical Reconstruction)

Historical tables often changed their increments as the values increased (e.g., counting by \(1\) unit up to \(10\), then by \(10\) up to \(60\)). MesoMath replicates this by allowing lists for the mmax and step parameters.

--> # Counting from 10 susi to 2 kus (step: 5 susi), then up to 12 kus (step: 1 kus)...
--> bl.metrolist("10 susi", ["2 kus", "12 kus"], ["5 susi", "1 kus"], verbose=True, fractions=1)

Babylonian length measurement
danna <-30- us <-60- ninda <-12- kus <-30- susi
|Measurement         | Sexag. (ninda)  | Reciprocal  |
|--------------------|-----------------|-------------|
|1/3 kus             | 1:40            | 36          |
|1/2 kus             | 2:30            | 24          |
|2/3 kus             | 3:20            | 18          |
|5/6 kus             | 4:10            | 14:24       |
|1 kus               | 5               | 12          |
|1 kus 5 susi        | 5:50            | --igi nu--  |
|1 1/3 kus           | 6:40            | 9           |
|1 1/2 kus           | 7:30            | 8           |
|1 2/3 kus           | 8:20            | 7:12        |
|1 5/6 kus           | 9:10            | --igi nu--  |
|2 kus               | 10              | 6           |
|3 kus               | 15              | 4           |
|1/3 ninda           | 20              | 3           |
|1/3 ninda 1 kus     | 25              | 2:24        |
|1/2 ninda           | 30              | 2           |
|1/2 ninda 1 kus     | 35              | --igi nu--  |
|2/3 ninda           | 40              | 1:30        |
|2/3 ninda 1 kus     | 45              | 1:20        |
|5/6 ninda           | 50              | 1:12        |
|5/6 ninda 1 kus     | 55              | --igi nu--  |
|1 ninda             | 1               | 1           |

The table above is obviously a metrological table for horizontal lengths. If you wish to construct the same table for vertical lengths, use the parameter ubase=1 (kus):

--> bl.metrolist("10 susi", ["2 kus", "12 kus"], ["5 susi", "1 kus"], ubase=1,verbose=True, fractions=1)

Babylonian length measurement
danna <-30- us <-60- ninda <-12- kus <-30- susi
|Measurement         | Sexag. (kus)    | Reciprocal  |
|--------------------|-----------------|-------------|
|1/3 kus             | 20              | 3           |
|1/2 kus             | 30              | 2           |
|2/3 kus             | 40              | 1:30        |
|5/6 kus             | 50              | 1:12        |
|1 kus               | 1               | 1           |
|1 kus 5 susi        | 1:10            | --igi nu--  |
|1 1/3 kus           | 1:20            | 45          |
|1 1/2 kus           | 1:30            | 40          |
|1 2/3 kus           | 1:40            | 36          |
|1 5/6 kus           | 1:50            | --igi nu--  |
|2 kus               | 2               | 30          |
|3 kus               | 3               | 20          |
|1/3 ninda           | 4               | 15          |
|1/3 ninda 1 kus     | 5               | 12          |
|1/2 ninda           | 6               | 10          |
|1/2 ninda 1 kus     | 7               | --igi nu--  |
|2/3 ninda           | 8               | 7:30        |
|2/3 ninda 1 kus     | 9               | 6:40        |
|5/6 ninda           | 10              | 6           |
|5/6 ninda 1 kus     | 11              | --igi nu--  |
|1 ninda             | 12              | 5           |

This is the most authentic way to recreate segments of the Standard Metrological Tables used in the Old Babylonian period.

---

7.5 Exporting for Publication

The siblings .metrohtml() and .metrolatex() generate files or raw code ready for use in external editors.

Example: Generating an HTML table

--> bw.metrohtml('10 gin', '1 mana', '10 gin', verbose=True, file='weight_table')
--> Exported 6 rows to 'weight_table.html'

Example: Generating a \(\LaTeX\) table The \(\LaTeX\) output uses the booktabs package style for a professional, academic look:

\begin{table}[h]
  \centering
  \begin{tabular}{lll}
    \toprule
    Measurement & Sexag. (gin) & Reciprocal \\
    \midrule
    (1 u) gin & 10 & 6 \\
    1/3 mana & 20 & 3 \\
    \bottomrule
  \end{tabular}
\end{table}

Note on Compatibility: Some options are interdependent. For instance, actual=True (academic names) or fractions only trigger specific formatting when the system can resolve those units. Always use help(bw.metro_generator) to check the latest parameter overrides.

8. Historical Presets: The Proust Series

Manually determining the start, end, and increment values to replicate an archaeological tablet can be tedious. To solve this, MesoMath includes metrology_presets based on the work of Christine Proust (e.g., Tablettes mathématiques de Nippur).

These are pre-configured in babcalc under the following aliases:

• clist: Capacity Series (Proust 8.1)

• wlist: Weight Series (Proust 8.2)

• slist: Surface Series (Proust 8.3)

• llist: Length Series (Proust 8.4)

but for your scripts you need to import them:

from mesomath.metrology_presets import CAPACITY_PROUST_81 as clist
from mesomath.metrology_presets import WEIGHT_PROUST_82 as wlist
from mesomath.metrology_presets import SURFACE_PROUST_83 as slist
from mesomath.metrology_presets import LENGTH_PROUST_84 as llist

8.1 Exploring a Preset

You can inspect the structure of a series by simply typing its name. This reveals the “curriculum steps” used in ancient scribal training:

--> clist
MetrologySeries: Proust 8.1 Capacities (se)
-----------------------------------------------------------------
Step   | Start Value     | End Value       | Increment
-----------------------------------------------------------------
0      | 1 gin           | 3 gin           | 30 se
1      | 3 gin           | 20 gin          | 1 gin
2      | 20 gin          | 2 sila          | 10 gin
3      | 2 sila          | 2 ban           | 1 sila
4      | 2 ban           | 1 bariga        | 5 sila
5      | 1 bariga        | 1 gur           | 1 ban
6      | 1 gur           | 2 gur           | 1 bariga
7      | 2 gur           | 20 gur          | 1 gur
8      | 20 gur          | 120 gur         | 10 gur
9      | 120 gur         | 1200 gur        | 60 gur
10     | 1200 gur        | 7200 gur        | 600 gur
11     | 7200 gur        | 72000 gur       | 3600 gur
12     | 72000 gur       | 216000 gur      | 36000 gur
-----------------------------------------------------------------
--> clist.nframes
13

8.2 Using .select() to Generate Tables

The real power of these presets lies in the .select() method. This allows you to pick specific ranges from the historical series and feed them directly into .metrolist() (or its siblings .metrohtml() / .metrolatex()).

If you want to reconstruct the segment of a capacity list from Step 2 to Step 4 (covering measurements from 20 gin up to 1 bariga with their historically accurate shifting increments):

--> # Extract start, end, and increment list for steps 2 through 4
--> a, b, c = clist.select(2, 4)
--> # Generate the segmented metrological list
--> bc.metrolist(a, b, c)

Babylonian capacity measurement
gur <-5- bariga <-6- ban <-10- sila <-60- gin <-180- se
|Measurement         |
|--------------------|
|20 gin              |
|30 gin              |
|40 gin              |
|50 gin              |
|1 sila              |
|1 sila 10 gin       |
|1 sila 20 gin       |
|1 sila 30 gin       |
|1 sila 40 gin       |
|1 sila 50 gin       |
|2 sila              |
|3 sila              |
|4 sila              |
|5 sila              |
|6 sila              |
|7 sila              |
|8 sila              |
|9 sila              |
|1 ban               |
|1 ban 1 sila        |
|1 ban 2 sila        |
|1 ban 3 sila        |
|1 ban 4 sila        |
|1 ban 5 sila        |
|1 ban 6 sila        |
|1 ban 7 sila        |
|1 ban 8 sila        |
|1 ban 9 sila        |
|2 ban               |
|2 ban 5 sila        |
|3 ban               |
|3 ban 5 sila        |
|4 ban               |
|4 ban 5 sila        |
|5 ban               |
|5 ban 5 sila        |
|1 bariga            |

8.3 Why use Presets?

1. Academic Accuracy: You don’t have to guess the increments used in ancient Nippur; they are already encoded.

2. Efficiency: It allows for the rapid creation of comparative tables for papers or classroom presentations.

3. Cross-Validation: Use these lists to verify if a broken fragment of a tablet follows the standard curriculum steps.

Pro Tip: You can combine these presets with the advanced formatting seen earlier. For example, bc.metrolatex(*clist.select(0, 2), verbose=True) will generate a high-quality LaTeX table of the earliest capacity measures, including their sexagesimal reciprocals.

8.4 Custom Metrology Series

While the Proust presets cover standard academic needs, you can create your own MetrologySeries. This is particularly useful when working with non-standard archives or specific commodities.

By passing integers instead of strings, you can define the series based on the absolute count of the smallest unit (e.g., se for weights or volumes).

--> from mesomath.metrology_presets import MetrologySeries

--> # Define a series using raw integer values
--> my_series = MetrologySeries(
...     name='Silver Logistics',
...     ini=1000,
...     endlist=[1500, 2500],
...     inclist=[100, 200],
...     unit_class='Weight'
... )

--> # Display the custom steps
--> my_series
MetrologySeries: Silver Logistics (Weight)
-----------------------------------------------------------------
Step   | Start Value     | End Value       | Increment
-----------------------------------------------------------------
0      | 1000            | 1500            | 100
1      | 1500            | 2500            | 200
-----------------------------------------------------------------

Now, because we used integers, we can apply it to any class; for instance:

--> a, b, c = my_series.select(0,1)
--> bc.metrolist(a,b,c)

Babylonian capacity measurement
gur <-5- bariga <-6- ban <-10- sila <-60- gin <-180- se
|Measurement         |
|--------------------|
|5 gin 100 se        |
|6 gin 20 se         |
|6 gin 120 se        |
|7 gin 40 se         |
|7 gin 140 se        |
|8 gin 60 se         |
|8 gin 160 se        |
|10 gin              |
|11 gin 20 se        |
|12 gin 40 se        |
|13 gin 60 se        |
|13 gin 160 se       |

MesoMath’s ability to interpret this type of integer-based preset definition is probably useless beyond the developer’s scope. Measurements such as ‘1 sila’, ‘1/3 ninda’, etc., will normally be used.

8.5 Specialized Formatting: subst, incipit and colophon

When generating the final table, you can add contextual information to the output to better reflect the nature of the transaction or the document:

• subst: Appends a specific string (like the commodity name) to the measurements.

• incipit: If set to True (or 1), it only places the subst label at the very first and very last rows of each segment, mimicking the “header/footer” style often seen in administrative records.

• width: Manually sets the character width of the table columns.

--> # Using the custom series for Weight (bw)
--> a, b, c = my_series.select(0, 1)
--> bw.metrolist(a, b, c, width=37, subst='ku-babbar', incipit=1, verbose=1)

Babylonian weight measurement
gu <-60- mana <-60- gin <-180- se
|Measurement                          | Sexag. (gin)    | Reciprocal  |
|-------------------------------------|-----------------|-------------|
|(5 dis) gin (1 ges 4 u) se ku-babbar | 5:33:20         | 10:48       |
|(6 dis) gin (2 u) se                 | 6:6:40          | --igi nu--  |
|(6 dis) gin (2 ges) se               | 6:40            | 9           |
|(7 dis) gin (4 u) se                 | 7:13:20         | --igi nu--  |
|(7 dis) gin (2 ges 2 u) se           | 7:46:40         | --igi nu--  |
|(8 dis) gin (1 ges) se               | 8:20            | 7:12        |
|(8 dis) gin (2 ges 4 u) se ku-babbar | 8:53:20         | 6:45        |
|(1 u) gin                            | 10              | 6           |
|(1 u 1 dis) gin (2 u) se             | 11:6:40         | 5:24        |
|(1 u 2 dis) gin (4 u) se             | 12:13:20        | --igi nu--  |
|(1 u 3 dis) gin (1 ges) se           | 13:20           | 4:30        |
|(1 u 3 dis) gin (2 ges 4 u) se       | 13:53:20        | 4:19:12     |

In this example, ku-babbar (silver) is used as the substance. Notice how incipit=1 ensures the label is not repeated on every single line, making the table cleaner and historically more authentic.

Finally, we can add a colophon:

--> bw.metrolist(a, b, c, width=37, subst='ku-babbar', incipit=1, verbose=1, colophon=1)

Babylonian weight measurement
gu <-60- mana <-60- gin <-180- se
|Measurement                          | Sexag. (gin)    | Reciprocal  |
|-------------------------------------|-----------------|-------------|
|(5 dis) gin (1 ges 4 u) se ku-babbar | 5:33:20         | 10:48       |
|(6 dis) gin (2 u) se                 | 6:6:40          | --igi nu--  |
|(6 dis) gin (2 ges) se               | 6:40            | 9           |
|(7 dis) gin (4 u) se                 | 7:13:20         | --igi nu--  |
|(7 dis) gin (2 ges 2 u) se           | 7:46:40         | --igi nu--  |
|(8 dis) gin (1 ges) se               | 8:20            | 7:12        |
|(8 dis) gin (2 ges 4 u) se ku-babbar | 8:53:20         | 6:45        |
|(1 u) gin                            | 10              | 6           |
|(1 u 1 dis) gin (2 u) se             | 11:6:40         | 5:24        |
|(1 u 2 dis) gin (4 u) se             | 12:13:20        | --igi nu--  |
|(1 u 3 dis) gin (1 ges) se           | 13:20           | 4:30        |
|(1 u 3 dis) gin (2 ges 4 u) se       | 13:53:20        | 4:19:12     |
--------------------------------------------------
| Grand Total: (1 dis) 5/6 mana (1 dis) gin (2 u) se ku-babbar
| Number of lines: 12 | Scribe: MesoMath 2.0.0 |
| April 2026 |
--------------------------------------------------

The colophon=True argument adds a summary block at the end of the table, including the total sum of the measurements, the line count, and the “scribe” (software version), mimicking the metadata found at the end of many ancient tablets.

9. Reverse Metrological Search: .lookup()

One of the greatest challenges in Mesopotamian mathematics is the absence of an absolute “decimal point.” A number like 20 could represent \(20\), \(20 \times 60\), or even \(20/60\) depending on the context.

The @classmethod .lookup() allows you to perform a reverse search. Given an abstract sexagesimal value, MesoMath scans across multiple orders of magnitude to find every possible physical measurement that matches that value.

9.1 Basic Usage

By default, .lookup() searches for matches relative to the system’s base unit.

--> bl.lookup('20')

Looking for Babylonian length measurement with Abstract = 20
Base reference unit: ninda
-------------------------------------------------------------
2400 danna           <- 20
40 danna             <- 20
20 us                <- 20
20 ninda             <- 20
4 kus                <- 20
2 susi               <- 20

9.2 Filters and Formatting

You can refine your search or change the output format to match your publication requirements:

• Strict Matching (strict=True): Only returns results where the sexagesimal string matches your input exactly (useful for filtering out fractional approximations).

• Epigraphic Output: Use translit=True or cuneiform=True to see the results as they would appear on a tablet.

• Detailed View (verbose=True): Includes the modern SI equivalent (meters, kg, etc.) for every potential match.

--> # Looking for a capacity value in cuneiform with detailed SI info
--> from mesomath.npvs import Bcap
--> Bcap.lookup('1:10', cuneiform=True, verbose=True)

Looking for Babylonian capacity measurement with Abstract = 1:10
Base reference unit: gin
-----------------------------------------------------------------
Measure:   𒐞 𒐘 𒄥
Equiv.:    252000.0 litres
Abstract:   𒐕 𒌋  

Measure:   𒌋 𒐂 𒄥
Equiv.:    4200.0 litres
Abstract:   𒐕 𒌋  

Measure:   𒁹 𒑏 𒊺
Equiv.:    70.0 litres
Abstract:   𒐕 𒌋  

Measure:   𒁹 𒋡 𒌋 𒂆
Equiv.:    1.1666666666666665 litres
Abstract:   𒐕 𒌋  

Measure:   𒁹 𒂆 𒊺 𒅆 𒐋 𒅅 𒂆
Equiv.:    0.019444444444444445 litres
Abstract:   𒐕 𒌋  

Measure:   𒐈 𒊺
Equiv.:    0.0002777777777777778 litres
Abstract:   𒐕 

9.3 Parameter Reference

Parameter	Type	Description
value	str|int	The abstract sexagesimal value (e.g., '1:20' or 80).
ubase	int	The unit index to use as the “positional zero”. Defaults to the class standard.
strict	bool	If True, only matches identical sexagesimal strings.
translit	bool	Displays measurements in Nippur-style transliteration.
cuneiform	bool	Displays measurements and abstract values in Unicode Cuneiform.
verbose	bool	Adds modern SI equivalents and detailed breakdown to each result.

Scribe’s Tip: Use .lookup() when you find an isolated number in a field of a table. It will help you narrow down the most plausible metrological category based on the physical dimensions of the object you are studying.

III. Epigraphy: From Math to Tablet

NAM-DUB-SAR
𒉆𒁾𒊬

MesoMath is first and foremost a high-precision calculator. However, its primary objective extends beyond mathematical correctness. A significant effort has been made to include two representations that reflect how quantities were actually recorded on clay: transliteration and original cuneiform characters.

1. Transliteration: The .translit Property

MesoMath incorporates the composite metrological tables of the Old Babylonian Period (Nippur) published by Proust (2009) as the foundation for its transliteration engine. To achieve a representation faithful to ancient scribal practices, the library employs a two-step process:

1. Greedy Decomposition: The internal decimal value (self.dec) is decomposed into the largest possible values corresponding to specific graphemes present in Proust’s composite lists.

2. Post-processing: The resulting tokens are concatenated and re-analyzed to regroup identical units and recalculate coefficients (e.g., aggregating multiple še or gin2 tokens), ensuring historical accuracy in the final string.

--> a = bc(11223344)
--> a.translit
'3(aš) gur 2(barig) 1(ban2) še 9(diš) sila3 1(u) 1(diš) 5/6 gin2 1(u) 4(diš) še'

Reliability Limits

The .translit property is optimized for the standard ranges found in archaeological contexts. Beyond these limits, historical systems often diverged or used non-standard notations.

Domain	Limit (Traditional)	Limit (Metric/SI)
Capacity	(2 sargal) gur (432,000 gur)	129,600,000 litres
Weight	(2 sargal) gu2 (432,000 gu2)	12,960,000 kg
Surface	(2 sargal) gan2 (129,600 gan2)	466,560,000 m²
Length	(2 ges2) danna (120 danna)	1,296,000 m

⚠️ Warning: For values exceeding these limits, the transliteration engine enters experimental territory where results may become unpredictable.

⚠️ Note on Attested Models: MesoMath adheres strictly to the metrological structures attested in the Nippur corpus (Proust 2009). When a value lacks an attested model within these lists, the engine purposefully returns (?) rather than attempting a synthetic extrapolation. This design choice prioritizes philological integrity, ensuring the user is explicitly notified when a calculation enters non-attested territory.

Note on Volume and Brick Metrology

In Babylonian practice, Volumes and Brick counts do not have a dedicated unit system; they are expressed using the Surface system (Bsur).

• Volumes are conceived as a surface area with a default thickness of 1 kuš3 (cubit).

• Bricks are standardized into volumes, allowing scribes to calculate counts via “surface-volume” logic.

MesoMath’s .translit property correctly reflects this by using surface units (sar, gan2, etc.) when calling volume or brick objects.

---

2. Transliteration in Tables

You can generate metrological lists and tables using professional transliteration by passing the translit=True flag. This is the preferred method for generating data for academic publications.

--> # Generating a length list with transliteration and a colophon
--> bl.metrolist("1 kus", ["5 kus", "1 ninda"], ["10 susi", "1 kus"],
...             verbose=True, translit=True, width=25, colophon=True)

Babylonian length measurement
danna <-30- us <-60- ninda <-12- kus <-30- susi
|Measurement              | Sexag. (ninda)  | Reciprocal  |
|-------------------------|-----------------|-------------|
|1(diš) kuš3              | 5               | 12          |
|1(diš) 1/3 kuš3          | 6:40            | 9           |
|1(diš) 2/3 kuš3          | 8:20            | 7:12        |
|2(diš) kuš3              | 10              | 6           |
|2(diš) 1/3 kuš3          | 11:40           | --igi nu--  |
|2(diš) 2/3 kuš3          | 13:20           | 4:30        |
|3(diš) kuš3              | 15              | 4           |
|3(diš) 1/3 kuš3          | 16:40           | 3:36        |
|3(diš) 2/3 kuš3          | 18:20           | --igi nu--  |
|4(diš) kuš3              | 20              | 3           |
|4(diš) 1/3 kuš3          | 21:40           | --igi nu--  |
|4(diš) 2/3 kuš3          | 23:20           | --igi nu--  |
|5(diš) kuš3              | 25              | 2:24        |
|1/2 ninda                | 30              | 2           |
|1/2 ninda 1(diš) kuš3    | 35              | --igi nu--  |
|1/2 ninda 2(diš) kuš3    | 40              | 1:30        |
|1/2 ninda 3(diš) kuš3    | 45              | 1:20        |
|1/2 ninda 4(diš) kuš3    | 50              | 1:12        |
|1/2 ninda 5(diš) kuš3    | 55              | --igi nu--  |
|1(diš) ninda             | 1               | 1           |
--------------------------------------------------
| Grand Total: 8(diš) 1/2 ninda
| Number of lines: 20 | Scribe: MesoMath 2.0.0 |
| April 2026 |
--------------------------------------------------

---

3. Cuneiform: The .cuneiform Property

The cuneiform representation is derived directly from the .translit output. The engine maps each transliterated token to its corresponding Unicode glyph.

--> a = bc(11223344)
--> print(a.cuneiform)
𒐁 𒄥 𒑖 𒑏 𒊺 𒐎 𒋡 𒌋 𒁹 𒑜 𒂆 𒌋 𒐉 𒊺

--> print(*bc.scheme(actual=1))
gur <-5- bariga <-6- ban2 <-10- sila3 <-60- gin2 <-180- še
--> print(*bc.scheme(cuneiform=1))
𒄥   ╼5╾  𒉿   ╼6╾  𒑏   ╼10╾  𒋡   ╼60╾  𒂆   ╼180╾  𒊺

--> print(*bw.scheme(actual=1))
gu2 <-60- ma-na <-60- gin2 <-180- še
--> print(*bw.scheme(cuneiform=1))
𒄘   ╼60╾  𒈠 𒈾   ╼60╾  𒂆   ╼180╾  𒊺

--> print(*bs.scheme(actual=1))
GAN2 <-100- sar <-60- gin2 <-180- še
--> print(*bs.scheme(cuneiform=1))
𒃷   ╼100╾  𒊬   ╼60╾  𒂆   ╼180╾  𒊺

--> print(*bl.scheme(actual=1))
danna <-30- UŠ <-60- ninda <-12- kuš3 <-30- šu-si
--> print(*bl.scheme(cuneiform=1))
𒆜 𒁍   ╼30╾  𒍑   ╼60╾  𒃻   ╼12╾  𒌑   ╼30╾  𒋗 𒋛

Visualizing the Script

Cuneiform characters reside in the Supplementary Multilingual Plane of Unicode. To see them correctly, you must have a specialized font installed.

▯ Rendering Check: If you see empty boxes or “tofu” instead of wedges, please refer to the Cuneiform Support section for font recommendations and installation guides.

4. Cuneiform in Tables

--> # Generating a length list with cuneiform and a colophon
--> bl.metrolist("1 kus", ["5 kus", "1 ninda"], ["10 susi", "1 kus"],
...             verbose=True, cuneiform=True, width=25, colophon=True)

Babylonian length measurement
𒆜 𒁍   ╼30╾  𒍑   ╼60╾  𒃻   ╼12╾  𒌑   ╼30╾  𒋗 𒋛
|Measurement              | Sexag. (𒃻 )     | Reciprocal  |
|-------------------------|-----------------|-------------|
|𒁹 𒌑                      |  𒐙              | 𒌋𒐖          |
|𒁹 𒑚 𒌑                    |  𒐚 𒑩            |  𒑆          |
|𒁹 𒑛 𒌑                    |  𒑄 𒎙            |  𒑂 𒌋𒐖       |
|𒐖 𒌑                      | 𒌋               |  𒐚          |
|𒐖 𒑚 𒌑                    | 𒌋𒐕 𒑩            | 𒅆 𒉡         |
|𒐖 𒑛 𒌑                    | 𒌋𒐗 𒎙            |  𒐘 𒌍        |
|𒐈 𒌑                      | 𒌋𒐙              |  𒐘          |
|𒐈 𒑚 𒌑                    | 𒌋𒐚 𒑩            |  𒐗 𒌍𒐚       |
|𒐈 𒑛 𒌑                    | 𒌋𒑄 𒎙            | 𒅆 𒉡         |
|𒐉 𒌑                      | 𒎙               |  𒐗          |
|𒐉 𒑚 𒌑                    | 𒎙𒐕 𒑩            | 𒅆 𒉡         |
|𒐉 𒑛 𒌑                    | 𒎙𒐗 𒎙            | 𒅆 𒉡         |
|𒐊 𒌑                      | 𒎙𒐙              |  𒐖 𒎙𒐘       |
|𒈦 𒃻                      | 𒌍               |  𒐖          |
|𒈦 𒃻 𒁹 𒌑                  | 𒌍𒐙              | 𒅆 𒉡         |
|𒈦 𒃻 𒐖 𒌑                  | 𒑩               |  𒐕 𒌍        |
|𒈦 𒃻 𒐈 𒌑                  | 𒑩𒐙              |  𒐕 𒎙        |
|𒈦 𒃻 𒐉 𒌑                  | 𒑪               |  𒐕 𒌋𒐖       |
|𒈦 𒃻 𒐊 𒌑                  | 𒑪𒐙              | 𒅆 𒉡         |
|𒁹 𒃻                      |  𒐕              |  𒐕          |
--------------------------------------------------
| 𒋗 𒆸 𒃲: 𒐆 𒈦 𒃻
| 𒈬 𒋃 𒁉: 𒐀 | 𒁾 𒊬: MesoMath 2.0.0 |
| 𒌗 𒐂 𒐈 𒐈 𒐉 𒐋 𒈬 |
--------------------------------------------------

Babylonian length measurement
𒆜 𒁍 ╼30╾ 𒍑 ╼60╾ 𒃻 ╼12╾ 𒌑 ╼30╾ 𒋗 𒋛

Measurement	Sexag. (𒃻 )	Reciprocal
𒁹 𒌑	𒐙	𒌋𒐖
𒁹 𒑚 𒌑	𒐚 𒑩	𒑆
𒁹 𒑛 𒌑	𒑄 𒎙	𒑂 𒌋𒐖
𒐖 𒌑	𒌋	𒐚
𒐖 𒑚 𒌑	𒌋𒐕 𒑩	𒅆 𒉡
𒐖 𒑛 𒌑	𒌋𒐗 𒎙	𒐘 𒌍
𒐈 𒌑	𒌋𒐙	𒐘
𒐈 𒑚 𒌑	𒌋𒐚 𒑩	𒐗 𒌍𒐚
𒐈 𒑛 𒌑	𒌋𒑄 𒎙	𒅆 𒉡
𒐉 𒌑	𒎙	𒐗
𒐉 𒑚 𒌑	𒎙𒐕 𒑩	𒅆 𒉡
𒐉 𒑛 𒌑	𒎙𒐗 𒎙	𒅆 𒉡
𒐊 𒌑	𒎙𒐙	𒐖 𒎙𒐘
𒈦 𒃻	𒌍	𒐖
𒈦 𒃻 𒁹 𒌑	𒌍𒐙	𒅆 𒉡
𒈦 𒃻 𒐖 𒌑	𒑩	𒐕 𒌍
𒈦 𒃻 𒐈 𒌑	𒑩𒐙	𒐕 𒎙
𒈦 𒃻 𒐉 𒌑	𒑪	𒐕 𒌋𒐖
𒈦 𒃻 𒐊 𒌑	𒑪𒐙	𒅆 𒉡
𒁹 𒃻	𒐕	𒐕

𒋗 𒆸 𒃲: 𒐆 𒈦 𒃻
𒈬 𒋃 𒁉: 𒐀 𒁾 𒊬: MesoMath 2.0.0
𒌗 𒐂 𒐈 𒐈 𒐉 𒐋 𒈬

IV. Socio-Economic Applications

In the ancient Near East, mathematics was the language of management. MesoMath provides specialized methods to solve the three pillars of the Babylonian economy: labor management, food distribution, and silver-based accounting.

1. Labor and Rations

The following methods allow you to calculate the human and caloric cost of a project without manually navigating reciprocal tables.

Labor Cost: .labor_cost()

This method calculates the total “man-days” required for a project. You provide the total volume of work (e.g., a canal to be excavated) and the work quota (the amount one man is expected to finish in one day).

--> # Excavating a small canal of 10 sar volume
--> canal = bv('10 sar')
--> quota = '20 gin'  # Standard quota: 1/3 sar per man-day
--> wages = canal.labor_cost(quota)
--> print(f"{wages} man-days required.")
30.0 man-days required.

Food Management: .rations()

Once the labor force is calculated, the next step for an administrator is feeding them. This method calculates the total grain, beer, or oil required based on the daily ration per worker.

--> daily_grain_ration = '2 sila'
--> # Calculate total barley needed for the canal project
--> total_grain = canal.rations(work_man='20 gin', wage=daily_grain_ration)
--> total_grain
1 bariga

---

2. The Silver Standard: .silver_payments()

While rations were the primary means of subsistence, silver served as the unit of account for higher-level transactions and professional wages. The .silver_payments() method translates physical work into its equivalent weight in silver.

--> # A construction project involving 2 sar-b of bricks
--> bricks = bb('2 sar')
--> silver_wage = '8 se' # Daily wage in silver
--> # Calculate cost based on a quota of 1 sar-b per day
--> total_silver = bricks.silver_payments(work_man='1 sar', wage=silver_wage)
--> total_silver
16 se

---

3. Construction Engineering (Bbri)

As discussed in Section II-6, the Bbri class is not just for counting; it is a tool for architectural planning. By combining the Nalbanum coefficients with labor methods, you can estimate the entire lifecycle of a building project:

1. Volume: Calculate the physical space of the walls (Bvol).

2. Count: Convert volume to bricks using .bricks(nalbanum) (Bbri).

3. Logistics: Use .labor_cost() to see how many workers are needed to mold or carry those bricks.

Historical Context: The standard work quotas used in these examples (like 1/3 sar of earth per day) are derived directly from the Mathematical Susa Texts and the Old Babylonian “coefficient lists” (pikkurtum).

V. Automation and Extension

1. Scripting with babcalc

While the interactive REPL is ideal for exploration, research often requires batch processing of large datasets or the reproduction of complex calculations. babcalc acts as a command-line interface (CLI) that can execute Python scripts directly.

CLI Usage

$ babcalc -h
Usage:
  babcalc                Launch interactive REPL
  babcalc <script.py>    Execute a script and exit
  babcalc -i <script.py> Execute a script and stay in interactive mode

• The -i flag: This is essential for debugging. It runs your script and then leaves the session open, allowing you to inspect the final state of your variables.

• Compatibility: By design, babcalc -i does not auto-import its internal classes into the script’s namespace. This ensures that your .py scripts are standard Python code that can be shared and run by anyone with the mesomath library installed.

MesoMath is designed to handle multi-step mathematical procedures. A prime example is the reconstruction of ancient reciprocal algorithms. The following script implements two methods described by Duncan J. Melville (2005) to find the reciprocal of a multi-digit sexagesimal number.

Case Study: The Reciprocal of 2:5: Taken from Duncan J. Melville: Reciprocals and Reciprocal algorithms in Mesopotamian Mathematics (2005). In this example, we apply the “Simple Reciprocal Algorithm” and “The Technique” to find the inverse of \(2;5\). Save the following code as Melville.py:

# Example of use of `BabN` class

from mesomath.babn import BabN

# Example 1: Searching the reciprocal of 2:5  according to D. J. Melville (2005)
# from Table 2. Simple Reciprocal algorithm

d1 = BabN("2:5")
r1 = d1.tail()
r2 = r1.rec()
r3 = d1 * r2
r4 = r3.rec()
r5 = r4 * r2

print(f"{d1 = }")
print(f"{r1 = }")
print(f"{r2 = }")
print(f"{r3 = }")
print(f"{r4 = }")
print(f"{r5 = }\n")

print(f"Result: {r5 = }\n")

print(f"\nTesting: {d1 * r5 = }")

# Example 2: from Table 3. using *The Technique*

r1 = d1.tail()
r2 = r1.rec()
r3 = d1.head() * r2
r4 = r3 + BabN(1)
r5 = r4.rec()
r6 = r5 * r2

print(f"{d1 = }")
print(f"{r1 = }")
print(f"{r2 = }")
print(f"{r3 = }")
print(f"{r4 = }")
print(f"{r5 = }")
print(f"{r6 = }")

print(f"\nResult: {r6 = }")

print(f"\nTesting: {d1 * r6 = }")

Execution: Running this script via babcalc provides a step-by-step trace of the Babylonian logic:

$ babcalc Melville.py
d1 = 2:5
r1 = 5
r2 = 12
r3 = 25:0
r4 = 2:24
r5 = 28:48

Result: r5 = 28:48


Testing: d1 * r5 = 1:0:0:0
d1 = 2:5
r1 = 5
r2 = 12
r3 = 24
r4 = 25
r5 = 2:24
r6 = 28:48

Result: r6 = 28:48

Testing: d1 * r6 = 1:0:0:0

Expert Insight: The result 1:0:0:0 represents the sexagesimal unit. Since Babylonian math used a floating-place system, this confirms that \(2;5 \times 0;28,48 = 1\).

---

Another example of a script: Write a markdown table of the area of ​​squares based on their edge. Copy and paste the following code into a file named squares.py:

"""Write a markdown table of the area of ​​squares as a function of their edge.
"""
# Required imports
from mesomath import Blen as bl
from mesomath.utils import gen_multi_range as gmr
from mesomath.metrology_presets import LENGTH_PROUST_84 as llist


# Selecting range from Proust's presets
a,b,c = llist.select(4,6)

# Table header
output = "| Side | Surface |\n|:---|---:|\n"
# Table body
for _ in gmr(bl,a,b,c):
    ll = bl(_[0])
    ll2 = ll * ll

    output += f"| {ll.cuneiform:<20} | {ll2.cuneiform:<37} |\n"

# Printing
print(output)

Execution:

$ babcalc squares.py
| Side | Surface |
|:---|---:|
| 𒌋 𒃻                  | 𒀸 𒃷                                   |
| 𒎙 𒃻                  | 𒐂 𒃷                                   |
| 𒌍 𒃻                  | 𒑘 𒐁 𒃷                                 |
| 𒐏 𒃻                  | 𒑙 𒐂 𒃷                                 |
| 𒐏 𒐊 𒃻                | 𒌋 𒐀 𒃷 𒎙 𒐊 𒊬                           |
| 𒐐 𒃻                  | 𒌋 𒑘 𒀸 𒃷                               |
| 𒐐 𒐊 𒃻                | 𒌋 𒑙 𒃷 𒎙 𒐊 𒊬                           |
| 𒁹 𒍑                  | 𒎙 𒃷                                   |
| 𒁹 𒍑 𒌋 𒃻              | 𒎙 𒑙 𒀸 𒃷                               |
| 𒁹 𒍑 𒎙 𒃻              | 𒌍 𒑘 𒐂 𒃷                               |
| 𒁹 𒍑 𒌍 𒃻              | 𒐏 𒑘 𒐁 𒃷                               |
| 𒁹 𒍑 𒐏 𒃻              | 𒐐 𒑘 𒐂 𒃷                               |
| 𒁹 𒍑 𒐐 𒃻              | 𒐑 𒑙 𒀸 𒃷                               |
| 𒐖 𒍑                  | 𒐓 𒃷                                   |

or:

Side	Surface
𒌋 𒃻	𒀸 𒃷
𒎙 𒃻	𒐂 𒃷
𒌍 𒃻	𒑘 𒐁 𒃷
𒐏 𒃻	𒑙 𒐂 𒃷
𒐏 𒐊 𒃻	𒌋 𒐀 𒃷 𒎙 𒐊 𒊬
𒐐 𒃻	𒌋 𒑘 𒀸 𒃷
𒐐 𒐊 𒃻	𒌋 𒑙 𒃷 𒎙 𒐊 𒊬
𒁹 𒍑	𒎙 𒃷
𒁹 𒍑 𒌋 𒃻	𒎙 𒑙 𒀸 𒃷
𒁹 𒍑 𒎙 𒃻	𒌍 𒑘 𒐂 𒃷
𒁹 𒍑 𒌍 𒃻	𒐏 𒑘 𒐁 𒃷
𒁹 𒍑 𒐏 𒃻	𒐐 𒑘 𒐂 𒃷
𒁹 𒍑 𒐐 𒃻	𒐑 𒑙 𒀸 𒃷
𒐖 𒍑	𒐓 𒃷

---

Remastering Plimpton 322

from mesomath import BabN as bn

PLIMPTON_322 = [
    ["1:59:00:15", "1:59", "2:49", "1"],
    ["1:56:56:58:14:50:06:15", "56:07", "1:20:25", "2"],
    ["1:55:07:41:15:33:45", "1:16:41", "1:50:49", "3"],
    ["1:53:10:29:32:52:16", "3:31:49", "5:09:01", "4"],
    ["1:48:54:01:40", "1:05", "1:37", "5"],
    ["1:47:06:41:40", "5:19", "8:01", "6"],
    ["1:43:11:56:28:26:40", "38:11", "59:01", "7"],
    ["1:41:33:45:14:03:45", "13:19", "20:49", "8"],
    ["1:38:33:36:36", "8:01", "12:49", "9"],
    ["1:35:10:02:28:27:24:26:40", "1:22:41", "2:16:01", "10"],
    ["1:33:45", "45", "1:15", "11"],
    ["1:29:21:54:02:15", "27:59", "48:49", "12"],
    ["1:27:00:03:45", "2:41", "4:49", "13"],
    ["1:25:48:51:35:06:40", "29:31", "53:49", "14"],
    ["1:23:13:46:40", "56", "53", "15"],
    ]

KI_GLYPH = "\N{CUNEIFORM SIGN KI}"

# Pad with zeros if necesary
bn.fill = True

# Extrapolated "1" switch
use_ones = False
# Use e1 = 0 to use extrapolated "1", e1 = 2 to do not use it
e1 = 0 if use_ones else 2

output = "|Plimpton 322 Content|||||\n|:---|:---|:---|:---|:---|\n"
for line in PLIMPTON_322:
    clin = [bn(_).cuneiform(stroke=1, alter=1) for _ in line]
    output += f"| {clin[0][e1:]} | {clin[1]} | {clin[2]} | {KI_GLYPH} |{clin[3]} |\n"


print(output)

Plimpton 322

Plimpton 322 Content
𒑪𒑆 𒃵 𒌋𒐙	𒐕 𒑪𒑆	𒐖 𒑩𒑆	𒆠	𒐕
𒑪𒐚 𒑪𒐚 𒑪𒑄 𒌋𒐘 𒑪   𒐚 𒌋𒐙	𒑪𒐚  𒑂	𒐕 𒎙  𒎙𒐙	𒆠	𒐖
𒑪𒐙  𒑂 𒑩𒐕 𒌋𒐙 𒌍𒐗 𒑩𒐙	𒐕 𒌋𒐚 𒑩𒐕	𒐕 𒑪  𒑩𒑆	𒆠	𒐗
𒑪𒐗 𒌋  𒎙𒑆 𒌍𒐖 𒑪𒐖 𒌋𒐚	𒐗 𒌍𒐕 𒑩𒑆	𒐙  𒑆  𒐕	𒆠	𒐘
𒑩𒑄 𒑪𒐘  𒐕 𒑩	𒐕  𒐙	𒐕 𒌍𒑂	𒆠	𒐙
𒑩𒑂  𒐚 𒑩𒐕 𒑩	𒐙 𒌋𒑆	𒑄  𒐕	𒆠	𒐚
𒑩𒐗 𒌋𒐕 𒑪𒐚 𒎙𒑄 𒎙𒐚 𒑩	𒌍𒑄 𒌋𒐕	𒑪𒑆  𒐕	𒆠	𒑂
𒑩𒐕 𒌍𒐗 𒑩𒐙 𒌋𒐘  𒐗 𒑩𒐙	𒌋𒐗 𒌋𒑆	𒎙  𒑩𒑆	𒆠	𒑄
𒌍𒑄 𒌍𒐗 𒌍𒐚 𒌍𒐚	𒑄  𒐕	𒌋𒐖 𒑩𒑆	𒆠	𒑆
𒌍𒐙 𒌋   𒐖 𒎙𒑄 𒎙𒑂 𒎙𒐘 𒎙𒐚 𒑩	𒐕 𒎙𒐖 𒑩𒐕	𒐖 𒌋𒐚  𒐕	𒆠	𒌋
𒌍𒐗 𒑩𒐙	𒑩𒐙	𒐕 𒌋𒐙	𒆠	𒌋𒐕
𒎙𒑆 𒎙𒐕 𒑪𒐘  𒐖 𒌋𒐙	𒎙𒑂 𒑪𒑆	𒑩𒑄 𒑩𒑆	𒆠	𒌋𒐖
𒎙𒑂 𒃵  𒐗 𒑩𒐙	𒐖 𒑩𒐕	𒐘 𒑩𒑆	𒆠	𒌋𒐗
𒎙𒐙 𒑩𒑄 𒑪𒐕 𒌍𒐙  𒐚 𒑩	𒎙𒑆 𒌍𒐕	𒑪𒐗 𒑩𒑆	𒆠	𒌋𒐘
𒎙𒐗 𒌋𒐗 𒑩𒐚 𒑩	𒑪𒐚	𒑪𒐗	𒆠	𒌋𒐙

---

2. Advanced Topic: Extending Metrology

MesoMath’s greatest strength is its polymorphic architecture. You are not restricted to the built-in units. By inheriting from base classes like Blen (Length) or Bcap (Capacity), you can define custom systems for specific cities, periods, or professional niches.

The “Vertical Problem”: Custom Height Class

In many tablets, vertical measurements (depth of a canal, height of a wall) use length unit names but fixed ratios for calculation. We can create a dedicated bh (Babylonian Height) class in just a few lines:

from mesomath.npvs import Blen, Bsur, Bvol

class bh(Blen):
    title: str = "Babylonian Height Measurement"
    ubase: int = 1  # Standardizes calculations around the 'kus' (cubit)

Because bh inherits from Blen, it is fully compatible with the rest of the library. You can multiply a standard surface (Bsur) by your custom height (bh) to get a volume (Bvol) without any errors.

---

3. Case Study: Late Babylonian Period (LBP)

The metrology of the Late Babylonian period shifted significantly (e.g., the introduction of the GAR). We can implement this entire system by creating a new module (e.g., lateb.py):

from mesomath.npvs import Bcap, Bvol


class LBcap(Bcap):  # Capacity
    """This class implement Non-Place-Value System arithmetic
    for Late Babylonian Period capacity units:

        **gur <-5- bariga <-6- ban2 <-10- sila3 <-10- GAR**

    """

    title: str = "Late Babylonian capacity measurement"
    uname: list[str] = "gar sila ban bariga gur".split()
    aname: list[str] = "GAR sila3 ban2 bariga gur".split()
    ufact: list[int] = [10, 10, 6, 5]
    cfact: list[int] = [1, 10, 100, 600, 3000]
    siv: float = 0.1
    siu: str = "litres"
    ubase: int = 3  # bariga

    def vol(self) -> object:
        """Convert capacity to volume measurement

        :return: volume measurement
        :rtype: "Bvol"
        """
        return LBvol(int(round(self.dec/(100/6))))

class LBvol(Bvol):  # Volume
    """This class implement Non-Place-Value System arithmetic
    for Late Babylonian Period volume units:

        **GAN2 <-100- sar <-60- gin2 <-180- še**

    """
    title: str = "Late Babylonian volume measurement"

    def cap(self) -> object:
        """Convert volume to capacity measurement"""
        return LBcap(int(round(self.dec*(100/6))))

Running the Extension

Once defined, load your custom metrology into the calculator:

$ babcalc -i lateb.py

and use it:

--> a = LBcap('1000 sila')
--> b = a.vol()
--> b
3 gin 60 se
--> b.explain()
This is a Late Babylonian volume measurement: 3 gin 60 se
    Metrology:  gan <-100- sar <-60- gin <-180- se
    Factor with unit 'se':  1 180 10800 1080000
Measurement in terms of the smallest unit: 600 (se)
Sexagesimal floating value of the above: 10
Approximate SI value: 0.9999999999999999 cube meters
--> c=b.cap()
--> c
3 gur 1 bariga 4 ban
--> c.SI()
'1000.0 litres'
--> c.explain()
This is a Late Babylonian capacity measurement: 3 gur 1 bariga 4 ban
    Metrology:  gur <-5- bariga <-6- ban <-10- sila <-10- gar
    Factor with unit 'gar':  1 10 100 600 3000
Measurement in terms of the smallest unit: 10000 (gar)
Sexagesimal floating value of the above: 2:46:40
Approximate SI value: 1000.0 litres
-->
--> LBcap.metrolist('1 bariga','3 bariga', '1 ban',verbose=1)

Late Babylonian capacity measurement
gur <-5- bariga <-6- ban <-10- sila <-10- gar
|Measurement         | Sexag. (bariga) | Reciprocal  |
|--------------------|-----------------|-------------|
|1 bariga            | 1               | 1           |
|1 bariga 1 ban      | 1:10            | --igi nu--  |
|1 bariga 2 ban      | 1:20            | 45          |
|1 bariga 3 ban      | 1:30            | 40          |
|1 bariga 4 ban      | 1:40            | 36          |
|1 bariga 5 ban      | 1:50            | --igi nu--  |
|2 bariga            | 2               | 30          |
|2 bariga 1 ban      | 2:10            | --igi nu--  |
|2 bariga 2 ban      | 2:20            | --igi nu--  |
|2 bariga 3 ban      | 2:30            | 24          |
|2 bariga 4 ban      | 2:40            | 22:30       |
|2 bariga 5 ban      | 2:50            | --igi nu--  |
|3 bariga            | 3               | 20          |

etc. but we should also redefine the rest of the classes to ensure consistency in the operations with the new units.

---

Why Extend MesoMath?

1. Chronological Flexibility: Adapt the tool for Neo-Sumerian, Old Assyrian, or Seleucid data.

2. Regional Variations: Account for the different sila sizes used in Mari vs. Nippur.

3. Automatic Tools: Your custom classes automatically inherit .metrolist(), and .lookup() capabilities.

Extending Metrology: Limitations & Compatibility

While the arithmetic engine of MesoMath is highly flexible, the epigraphic layer is deeply rooted in specific historical corpora.

[!CAUTION] Epigraphic Compatibility Notice The epigraphic properties (.translit, .cuneiform) and the historical presets are strictly based on the metrology and habits of scribes from the Old Babylonian period (specifically the Nippur tradition).

Using these properties with custom metrologies defined by the user will predictably lead to inconsistent results, as the sign-mapping logic expects the standard Old Babylonian ratios and unit names.

Why this limitation?

The conversion from a decimal value to a cuneiform string is not a simple character replacement. It involves a complex mapping of:

1. Grapheme choice: Different signs for the same value depending on whether it is a capacity, weight, or length.

2. Standard Ratios: The automatic breakdown of units (e.g., gur to bariga) assumes the \(5:6:10:10\) ratio.

If you define a custom class for a different historical period, we recommend relying on the .prtf() (pretty print) or .sex() (sexagesimal) methods for output, as these are purely mathematical and remain consistent across any user-defined system.

---

𒍻 jccsvq 𒁾𒊬 𒐞𒐞𒐞 𒐗 𒐏 𒐋

VI. Reference & Appendices

Appendix A: Use of Systems C, S and G in MesoMath Metrology

According to Proust’s: Numerical and Metrological Graphemes: From Cuneiform to Transliteration. Table 9

Measurement	System	Unit	Class
capacities	C	gin2	Bcap
capacities	C	sila3	Bcap
capacities	C*	ban2	Bcap
capacities	C*	bariga	Bcap
capacities	S	gur	Bcap
weights	C	še	Bwei
weights	C	gin2	Bwei
weights	C	ma-na	Bwei
weights	S	gu2	Bwei
surfaces	C	še	Bsur, Bvol, Bbri
surfaces	C	gin2	Bsur, Bvol, Bbri
surfaces	C	sar	Bsur, Bvol, Bbri
surfaces	G	GAN2	Bsur, Bvol, Bbri
lengths	C	šu-si	Blen
lengths	C	kuš3	Blen
lengths	C	ninda	Blen
lengths	C	UŠ	Blen
lengths	C	danna	Blen

(*): Note These are not in the reference.

Appendix B: The Metrological Catalog

This appendix provides a complete reference of the units and conversion coefficients used in MesoMath v2.0.0. The systems follow the standard Old Babylonian (Nippur) tradition.

1. Overview of Metrological Chains

The following diagrams illustrate the ratios between units. Each arrow ╼ n ╾ indicates how many of the smaller unit (right) are contained in the larger unit (left).

Capacity (Bcap)

Used for liquids and dry grains. Base unit: sila3.

  gur  ╼5╾  bariga  ╼6╾  ban2  ╼10╾  sila3  ╼60╾  gin2  ╼180╾  še
  𒄥   ╼5╾    𒉿    ╼6╾   𒑏    ╼10╾    𒋡    ╼60╾   𒂆    ╼180╾  𒊺

Weight (Bwei)

Used for metals (silver, copper) and wool. Base unit: ma-na.

   gu2   ╼60╾   ma-na   ╼60╾   gin2   ╼180╾   še
   𒄘    ╼60╾   𒈠 𒈾   ╼60╾   𒂆    ╼180╾   𒊺

Surface (Bsur)

Used for land management. Base unit: sar.

  GAN2   ╼100╾   sar   ╼60╾   gin2   ╼180╾   še
   𒃷    ╼100╾   𒊬   ╼60╾    𒂆    ╼180╾   𒊺

Length (Blen)

Used for architecture and surveying. Base unit: ninda.

 danna  ╼30╾  UŠ  ╼60╾  ninda  ╼12╾  kuš3  ╼30╾  šu-si
 𒆜 𒁍   ╼30╾  𒍑  ╼60╾    𒃻    ╼12╾   𒌑   ╼30╾  𒋗 𒋛

---

2. Technical Coefficients and SI Equivalents

Para una consulta rápida, esta tabla resume los factores de conversión internos (ufact) y los valores aproximados en el Sistema Internacional (siv).

Category	Base Unit	Smallest Unit	Internal Ratios (ufact)	SI Equivalent (siv)
Capacity	sila3	še	[180, 60, 10, 6, 5]	1 sila3 ≈ 1.0 Litre
Weight	ma-na	še	[180, 60, 60]	1 ma-na ≈ 0.5 kg
Surface	sar	še	[180, 60, 100]	1 sar ≈ 36.0 m²
Length	ninda	šu-si	[30, 12, 60, 30]	1 ninda ≈ 6.0 m

---

3. Numerical and Specialized Systems (NPVS)

Beyond standard measurements, MesoMath implements the discrete counting systems and the specialized land-area system (System G). These follow the Non-Positional Value System (NPVS) logic used for administrative and historical records.

System S (BsyS): Sexagesimal Counting

Used for counting discrete objects (people, animals, objects). Base unit: aš.

 šar2-gal  ╼6╾  šar'u  ╼10╾  šar2  ╼6╾  geš'u  ╼10╾  geš  ╼6╾  u  ╼10╾  aš
    𒊹      ╼6╾    𒐬    ╼10╾   𒊬    ╼6╾    𒐞    ╼10╾   𒐕   ╼6╾  𒌋  ╼10╾  𒀸

System G (BsyG): Field Area (Sumerian Tradition)

Used for large scale field measurements. Base unit: iku.

 šar2-gal  ╼6╾  šar'u  ╼10╾  šar2  ╼6╾  bur'u  ╼10╾  bur3  ╼3╾  eše3  ╼6╾  iku
    𒊹      ╼6╾    𒐬    ╼10╾   𒊬    ╼6╾    𒐴    ╼10╾   𒌋     ╼3╾   𒑘    ╼6╾  𒀸

Historical Note: System G is the archaic precursor to the later surface metrology (Bsur). While Bsur is optimized for mathematical calculations, BsyG is the standard for administrative land management and surveyor reports.

System SKL (BsyK): Sumerian King List

A specialized variant for astronomical time periods (years). Base unit: diš.

 šar2-gal  ╼6╾  šar'u  ╼10╾  šar2  ╼6╾  geš'u  ╼10╾  geš  ╼6╾  u  ╼10╾  diš
    𒊹      ╼6╾    𒐬    ╼10╾   𒊬    ╼6╾    𒐞    ╼10╾   𒐕   ╼6╾  𒌋  ╼10╾  𒁹

---

4. Implementation Details

Each of these systems is implemented as a subclass of Npvs. When extending these classes, remember that:

• Abstract Values: All calculations are performed relative to the base unit (index defined by ubase).

• Storage: Values are stored as integers representing the smallest unit of the chain to avoid floating-point errors.

Appendix C Commodity Lists & Conversion factors.

Substance Symbols and others

You can access these terms. Example:

--> from mesomath.glyphs import subsdict
--> print(subsdict['ki_la2'])
𒆠 𒆷

Metals & Value

Subst	Glyph	Meaning
ku_babbar	𒆬 𒌓	Silver (kù-babbar), also weight
urudu	𒍏	Copper (urudu)
ku3_sig17	𒆬 𒄀	Gold (kù-sig17)

Crops & Liquids

Subst	Glyph	Meaning
se	𒊺	Barley (še), also capacity
ziz2	𒀾	Emmer wheat (zíz)
i3_gis	𒉌 𒄑	Sesame oil (ì-giš)
kas	𒁉	Beer (kaš / bi) - Standard vessel sign

Land & Livestock

Subst	Glyph	Meaning
a_sa	𒀀 𒊮	Field (a-šà), also surface
kiri6	𒊬	Orchard/Garden (kiri6)
gu4	𒄞	Ox (gu4)
udu	𒇻	Sheep (udu)

Textiles & Fibers

Subst	Glyph	Meaning
siki	𒋠	Wool (siki)
gada	𒃰	Linen (gada)
siki_gi	𒋠 𒄀	Native/Standard wool (siki-gi)

Fruits & Provisions

Subst	Glyph	Meaning
zu2_lum	𒍪 𒈝	Dates (zú-lum)
ges_tin	𒃾	Wine (geštin)
ga_ar3	𒂵 𒄯	Cheese/Curd (ga-àr)
i3_nun	𒉌 𒉣	Ghee/Butter (ì-nun)

Building & Resources

Subst	Glyph	Meaning
esir	𒀀 𒂍	Bitumen (esir2 / A.E2) - The most standard form
ges	𒄑	Wood/Beam (geš)
sig4	𒋞	Brick (sig4)
na4	𒉌	Stone (na4)

Personnel (Contextual)

Subst	Glyph	Meaning
lu2	𒇽	Man/Worker (lú)
geme2	𒊩	Female worker (gemé)
er3	𒀴	Slave/Servant (er3)

Mathematical States (for Metrotable)

Subst	Glyph	Meaning
igi_nu	𒅆 𒉡	Reciprocal not found (igi-nu)
igi_nu_du8	𒅆 𒉡 𒂃	Reciprocal does not open (igi-nu-du8)
a_ra2	𒀀 𒁺	Times (a-rá)

Geometry

1. Main Dimensions

Subst	Glyph	Meaning
sag	𒊕	Front / Width (Literally
dagal	𒂼	Breadth / Width (Used for the extent of an object or surface).
sag_dagal	𒊕 𒂼

2. Other Geometric Dimensions

Subst	Glyph	Meaning
us	𒍑	Length / Long (It is the companion of SAG; in a rectangle, UŠ is the long side and SAG the short side).
sukud	𒊩𒆪	Height (Used for the height of a wall or a tower).
bur	𒌋	Depth (In cuneiform: 𒁓)? (Common in texts about excavation of canals or wells).
gam	𒃵	Depth, curvature (GAM)
da	𒁕	Side / Flank (Refers to the edge or lateral line of a figure).
gid	𒁍	Length / Extension (Means
ki_la2	𒆠 𒆷	Excavation area
sahar	𒅖	Earth / Dust.

Administrative Terms

You can access these terms. Example:

--> from mesomath.glyphs import MAP_ADMIN as admin
--> print(admin['mu-kux'])
𒈬 𒁺

Subst	Glyph	Meaning
su_ningin_gal	𒋗 𒆸 𒃲	Total if sections
mu_sid_bi	𒈬 𒋃 𒁉	Your number of lines
dub	𒁾	Clay tablet
mu-kux	𒈬 𒁺	mu-kux(DU) Delivery. Indicates goods that enter the institution or warehouse.
zi-ga	𒍣 𒂵	Expense. Indicates what has been withdrawn or spent from the inventory.
la-ia	𒇲 𒉌	Deficit. (lá-ia3) It was used to indicate what was missing in an account or what an official still had to deliver.
nig-ka	𒃻 𒅗	Balance, the general term for the “account statement” or the process of auditing a ledger.
iti	𒌗	Date. Month / Time of creation.
dub-sar	𒁾 𒊬	Scribe
nu_til	𒉡 𒌀	Not finished.
ba_til	𒁀 𒌀	Finished.
mu	𒈬	Used for “year” in administrative dating contexts.
su_ti_a	𒋗 𒋾 𒀀	Received (šu-ti-a)
ib2_tag4	𒅁 𒋳	Remainder / Balance (ib2-tag4)
sa10	𒌓	Price / Equivalent (sa10 / sham)

Determinatives

You can access these terms. Example:

--> from mesomath.glyphs import DETERM
--> print(DETERM['ku3'])
𒆬

Subst	Glyph	Meaning
gi	𒄀	Reed, Crucial for alternative length measurements (gi = 1/2 ninda).
ku3	𒆬	Precious/Pure. It precedes metals.
dug	𒂁	Vessel. It precedes liquids.
